These are the known mechanical and performance specifications for your 2008 GAS GAS TXT 300 Raga.
Basic Specs
Engine
Displacement294.00 ccm (17.94 cubic inches)
Type
DetailsSingle cylinder, two-stroke
Max RPM
Compression
Bore/Stroke79.0 x 60.0 mm (3.1 x 2.4 inches)
Valves/Cylinder
FuelingCarburettor. Keihin
IgnitionCDI digital magnetic flywheel
ExhaustTitanium exhaust elbow
Lubrication2.5 % Mixture
CoolingLiquid
Drivetrain
Gearbox6-speed
Final DriveChain
ClutchMultidisc, hydraulically-operated
Driveline
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity3.10 litres (0.82 gallons)
Emissions
Chassis
Frame TypeEliptic profile made with CR-Mo and magnesium
Rake
Trail
Front Suspension40 mm adjustable telehydraulic fork
Front Travel
Rear SuspensionVariable progressivity system, single shock
Rear Travel
Seat
Seat Height665 mm (26.2 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance
Wheelbase1,330 mm (52.4 inches)
Dry Weight65.5 kg (144.4 pounds)
Wet Weight
Wheels & Brakes
Front Tire/Tyre
Rear Tire/Tyre
Front BrakesSingle disc
Front Brake Diameter185 mm (7.3 inches)
Rear BrakesSingle disc
Rear Brake Diameter150 mm (5.9 inches)
Wheels
Comments
