2008 Kawasaki KLX110 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2008 Kawasaki KLX110.

Basic Specs

Year2008
MakeKawasaki
ModelKawasaki KLX110
CostUS$ 1749. Prices depend on country, taxes, accessories, etc.

Engine

Displacement111.00 ccm (6.77 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.5:1
Bore/Stroke53.0 x 50.6 mm (2.1 x 2.0 inches)
Valves/Cylinder4
FuelingCarburettor. Keihin PB18
IgnitionCDI
Exhaust
LubricationForced, semi-dry sump
CoolingAir

Drivetrain

Gearbox3-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity3.78 litres (1.00 gallons)
Emissions

Chassis

Frame TypeBackbone frame, high-tensile steel
Rake25.5°
Trail
Front Suspension30mm hydraulic telescopic fork / 4.3 in.
Front Travel
Rear SuspensionSwingarm with single hydraulic shock / 4.2 in.
Rear Travel
Seat
Seat Height650 mm (25.6 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length1,554 mm (61.2 inches)
Total Width660 mm (26.0 inches)
Ground Clearance191 mm (7.5 inches)
Wheelbase1,064 mm (41.9 inches)
Dry Weight64.0 kg (141.1 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre70/70-19
Rear Tire/Tyre90/90-16
Front BrakesExpanding brake (drum brake)
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter215 mm (8.5 inches)
Wheels

Comments

It appears you're interested in specifications for the Kawasaki KLX110. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 111.00 ccm (6.77 cubic inches) of actual displacement before 9.5:1 compression. Fueling is metered via Carburettor. Keihin PB18 allowing this machine to produce its horsepower and torque. According to our records engine heat of the Kawasaki KLX110 is moderated by Air. You'll need to get familiar with the 3-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 70/70-19 and the rear is 90/90-16 . The entire package is supported by the frame, Backbone frame, high-tensile steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Expanding brake (drum brake) front brakes and Single disc rear brakes. The Kawasaki KLX110 was launched in 2008, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
