2008 KTM 144 SX Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2008 KTM 144 SX.

Basic Specs

Year2008
MakeKTM
ModelKTM 144 SX
Cost

Engine

Displacement143.60 ccm (8.76 cubic inches)
Type
DetailsSingle cylinder, two-stroke
Max RPM
Compression
Bore/Stroke56.0 x 58.5 mm (2.2 x 2.3 inches)
Valves/Cylinder
FuelingCarburettor. Keihin PWK 39
IgnitionKokusan digital Magnet CDI
ExhaustAluminium
LubricationMixture oil lubrication 1:40
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
ClutchWet multi-disc clutch, operated hydraulically
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity7.50 litres (1.98 gallons)
Emissions

Chassis

Frame TypeCental double-cradle-type 25 CrMo4
Rake27.0°
Trail
Front SuspensionWP USD 48 mm
Front Travel300 mm (11.8 inches)
Rear SuspensionWP Monoshock PDS
Rear Travel335 mm (13.2 inches)
Seat
Seat Height925 mm (36.4 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance390 mm (15.4 inches)
Wheelbase1,471 mm (57.9 inches)
Dry Weight90.8 kg (200.2 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre80/100-21
Rear Tire/Tyre100/90-19
Front BrakesSingle disc
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the KTM 144 SX. This Enduro / offroad model is powered by a Single cylinder, two-stroke engine with 143.60 ccm (8.76 cubic inches) of actual displacement before compression. Fueling is metered via Carburettor. Keihin PWK 39 allowing this machine to produce its horsepower and torque. According to our records engine heat of the KTM 144 SX is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 80/100-21 and the rear is 100/90-19 . The entire package is supported by the frame, Cental double-cradle-type 25 CrMo4. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The KTM 144 SX was launched in 2008, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
