2008 Kymco Agility 50 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2008 Kymco Agility 50.

Basic Specs

Year2008
MakeKymco
ModelKymco Agility 50
Cost

Engine

Displacement49.50 ccm (3.02 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression11.0:1
Bore/Stroke39.0 x 41.1 mm (1.5 x 1.6 inches)
Valves/Cylinder
Fueling
IgnitionCDI
Exhaust
Lubrication
CoolingAir

Drivetrain

GearboxAutomatic
Final DriveBelt
Clutch
Driveline

Performance

Horespower3.50 HP (2.6 kW)
Torque3.20 Nm (0.3 kgf-m or 2.4 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity5.00 litres (1.32 gallons)
Emissions

Chassis

Frame TypePine under bone
Rake
Trail
Front Suspension
Front Travel
Rear Suspension
Rear Travel
Seat
Seat Height790 mm (31.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,130 mm (44.5 inches)
Total Length1,830 mm (72.0 inches)
Total Width690 mm (27.2 inches)
Ground Clearance125 mm (4.9 inches)
Wheelbase
Dry Weight92.5 kg (203.9 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-12
Rear Tire/Tyre130/70-12
Front BrakesSingle disc
Front Brake Diameter180 mm (7.1 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter110 mm (4.3 inches)
Wheels

Comments

It appears you're interested in specifications for the Kymco Agility 50. This Scooter model is powered by a Single cylinder, four-stroke engine with 49.50 ccm (3.02 cubic inches) of actual displacement before 11.0:1 compression. Fueling is metered via allowing this machine to produce its 3.50 HP (2.6 kW) horsepower and 3.20 Nm (0.3 kgf-m or 2.4 ft.lbs) torque. According to our records engine heat of the Kymco Agility 50 is moderated by Air. You'll need to get familiar with the Automatic transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 120/70-12 and the rear is 130/70-12 . The entire package is supported by the frame, Pine under bone. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Expanding brake (drum brake) rear brakes. The Kymco Agility 50 was launched in 2008, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
