These are the known mechanical and performance specifications for your 2010 BMW R 1200 GS Adventure.
Basic Specs
Engine
Displacement1170.00 ccm (71.39 cubic inches)
Type
DetailsTwo cylinder boxer, two-stroke
Max RPM
Compression12.0:1
Bore/Stroke101.0 x 73.0 mm (4.0 x 2.9 inches)
Valves/Cylinder4
FuelingInjection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin spark ignition
Ignition
ExhaustClosed-loop 3-way catalytic converter, emission standard EU-3
Lubrication
CoolingOil & air
Drivetrain
Gearbox6-speed
Final DriveShaft drive (cardan)
ClutchSingle dry plate clutch, hydraulically operated
Driveline
Performance
Horespower103.25 HP (75.4 kW)
Torque115.00 Nm (11.7 kgf-m or 84.8 ft.lbs)
Top Speed
Fuel Economy & Polution
Fuel Consumption4.60 litres/100 km (21.7 km/l or 51.13 mpg)
Fuel Capacity33.00 litres (8.72 gallons)
Emissions106.7 CO2 g/km. (CO2 - Carbon dioxide emission)
Chassis
Frame TypeTwo-section frame consisting of front and rear sections, load- bearing engine-gearbox unit
Rake24.8°
Trail89 mm (3.5 inches)
Front SuspensionBMW Motorrad Telelever
Front Travel210 mm (8.3 inches)
Rear SuspensionCast aluminium single-sided swing arm with BMW Motorrad Paralever
Rear Travel220 mm (8.7 inches)
Seat
Seat Height910 mm (35.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,525 mm (60.0 inches)
Total Length2,240 mm (88.2 inches)
Total Width990 mm (39.0 inches)
Ground Clearance
Wheelbase1,510 mm (59.4 inches)
Dry Weight223.0 kg (491.6 pounds)
Wet Weight256.0 kg (564.4 pounds)
Wheels & Brakes
Front Tire/Tyre110/80-R19
Rear Tire/Tyre150/70-R17
Front BrakesDouble disc
Front Brake Diameter305 mm (12.0 inches)
Rear BrakesSingle disc
Rear Brake Diameter265 mm (10.4 inches)
Wheels
