2010 KTM 65 SX Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2010 KTM 65 SX.

Basic Specs

Year2010
MakeKTM
ModelKTM 65 SX
Cost

Engine

Displacement64.90 ccm (3.96 cubic inches)
Type
DetailsSingle cylinder, two-stroke
Max RPM
Compression
Bore/Stroke45.0 x 40.8 mm (1.8 x 1.6 inches)
Valves/Cylinder
FuelingCarburettor. Mikuni TM 24
IgnitionAET digital
ExhaustLubrication
LubricationMixture oil lubrication 1:60
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchWet mDouble disk clutch, operated hydraulically
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity3.50 litres (0.92 gallons)
Emissions

Chassis

Frame TypeDouble grinded central double-cradle-type frame
Rake25.5°
Trail
Front SuspensionMarzocchi USD 35 mm fork
Front Travel220 mm (8.7 inches)
Rear SuspensionWP mono shock
Rear Travel270 mm (10.6 inches)
Seat
Seat Height750 mm (29.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance280 mm (11.0 inches)
Wheelbase1,137 mm (44.8 inches)
Dry Weight55.4 kg (122.1 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre60/100-14
Rear Tire/Tyre80/100-12
Front BrakesSingle disc. Bremo
Front Brake Diameter198 mm (7.8 inches)
Rear BrakesSingle disc. Bremo
Rear Brake Diameter160 mm (6.3 inches)
Wheels

Comments

It appears you're interested in specifications for the KTM 65 SX. This Minibike, cross model is powered by a Single cylinder, two-stroke engine with 64.90 ccm (3.96 cubic inches) of actual displacement before compression. Fueling is metered via Carburettor. Mikuni TM 24 allowing this machine to produce its horsepower and torque. According to our records engine heat of the KTM 65 SX is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 60/100-14 and the rear is 80/100-12 . The entire package is supported by the frame, Double grinded central double-cradle-type frame. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Bremo front brakes and Single disc. Bremo rear brakes. The KTM 65 SX was launched in 2010, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Intended for children.
