These are the known mechanical and performance specifications for your 2011 Derbi Sonar 125 4T.
Basic Specs
Year2011
MakeDerbi
ModelDerbi Sonar 125 4T
TypeScooter
Cost Euro 1882. Prices depend on country, taxes, accessories, etc.
Engine
Displacement124.00 ccm (7.57 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.6:1
Bore/Stroke57.0 x 48.6 mm (2.2 x 1.9 inches)
Valves/Cylinder
FuelingCarburettor
Ignition
Exhaust
LubricationMechanical oil pump
CoolingAir
Drivetrain
GearboxAutomatic
Final DriveBelt
ClutchAutomatic centrifugal
Driveline
Performance
Horespower10.60 HP (7.7 kW)
Torque9.60 Nm (1.0 kgf-m or 7.1 ft.lbs)
Top Speed
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity6.00 litres (1.59 gallons)
Emissions
Chassis
Frame Type
Rake
Trail
Front Suspension32 mm fork.
Front Travel76 mm (3.0 inches)
Rear SuspensionMonoshock
Rear Travel64 mm (2.5 inches)
Seat
Seat Height805 mm (31.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length1,930 mm (76.0 inches)
Total Width740 mm (29.1 inches)
Ground Clearance
Wheelbase1,325 mm (52.2 inches)
Dry Weight99.0 kg (218.3 pounds)
Wet Weight
Wheels & Brakes
Front Tire/Tyre90/80-16
Rear Tire/Tyre110/80-14
Front BrakesSingle disc
Front Brake Diameter220 mm (8.7 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter140 mm (5.5 inches)
Wheels
Comments
Spanish scooter.
