2011 Harley-Davidson FXDWG Dyna Wide Glide Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2011 Harley-Davidson FXDWG Dyna Wide Glide.

Basic Specs

Year2011
MakeHarley-Davidson
ModelHarley-Davidson FXDWG Dyna Wide Glide
CostUS$ 14499. Euro 14795. UK £ 11490. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1573.25 ccm (96.00 cubic inches)
TypeTwin Cam 96
DetailsV2, four-stroke
Max RPM
Compression9.2:1
Bore/Stroke95.3 x 111.3 mm (3.8 x 4.4 inches)
Valves/Cylinder2
FuelingInjection. Electronic Sequential Port Fuel Injection
Ignition
ExhaustChrome 2-1-2 Tommy Gun exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveBelt
ClutchMulti-plate, we
DrivelinePrimary Drive: Chain, 34/46 ratio. Final Drive: Belt, 32/66 ratio

Performance

Horespower
Torque125.00 Nm (12.7 kgf-m or 92.2 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity17.79 litres (4.70 gallons)
Emissions

Chassis

Frame TypeMild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded
Rake34.0°
Trail130 mm (5.1 inches)
Front Suspension49 mm with polished aluminum fork triple clamp and dual-rate springs
Front Travel76 mm (3.0 inches)
Rear SuspensionCoil-over shock
Rear Travel
Seat
Seat Height648 mm (25.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,387 mm (94.0 inches)
Total Width
Ground Clearance107 mm (4.2 inches)
Wheelbase1,735 mm (68.3 inches)
Dry Weight293.5 kg (647.0 pounds)
Wet Weight301.6 kg (665.0 pounds)

Wheels & Brakes

Front Tire/Tyre80/90-21
Rear Tire/Tyre180/60-B17
Front BrakesDouble disc. 4-piston
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. 2-piston
Rear Brake Diameter292 mm (11.5 inches)
WheelsBlack, Laced Steel

Comments

It appears you're interested in specifications for the Harley-Davidson FXDWG Dyna Wide Glide. This Custom / cruiser model is powered by a Twin Cam 96 V2, four-stroke engine with 1573.25 ccm (96.00 cubic inches) of actual displacement before 9.2:1 compression. Fueling is metered via Injection. Electronic Sequential Port Fuel Injection allowing this machine to produce its horsepower and 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) torque. According to our records engine heat of the Harley-Davidson FXDWG Dyna Wide Glide is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 80/90-21 and the rear is 180/60-B17 . The entire package is supported by the frame, Mild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. 4-piston front brakes and Single disc. 2-piston rear brakes. The Harley-Davidson FXDWG Dyna Wide Glide was launched in 2011, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
