2011 Hyosung Rapier 450 Quad Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2011 Hyosung Rapier 450 Quad.

Basic Specs

Year2011
MakeHyosung
ModelHyosung Rapier 450 Quad
TypeATV
Cost

Engine

Displacement448.80 ccm (27.39 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression12.0:1
Bore/Stroke96.0 x 62.0 mm (3.8 x 2.4 inches)
Valves/Cylinder4
FuelingCarburettor
Ignition
Exhaust
LubricationSemi dry sump
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveChain
ClutchWet, Multiplate
DrivelineChain 520, With reverse.

Performance

Horespower50.00 HP (36.5 kW)
Torque47.64 Nm (4.9 kgf-m or 35.1 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity11.00 litres (2.91 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionIndependent double A-arm,
Front Travel
Rear Suspension Aluminum alloy swing arm,
Rear Travel
Seat
Seat Height
Alt. Seat Height
Total Height1,155 mm (45.5 inches)
Total Length1,835 mm (72.2 inches)
Total Width1,170 mm (46.1 inches)
Ground Clearance260 mm (10.2 inches)
Wheelbase1,250 mm (49.2 inches)
Dry Weight
Wet Weight

Wheels & Brakes

Front Tire/Tyre175/75-10
Rear Tire/Tyre255/55-9
Front BrakesDouble disc
Front Brake Diameter170 mm (6.7 inches)
Rear BrakesSingle disc
Rear Brake Diameter240 mm (9.4 inches)
Wheels

Comments

It appears you're interested in specifications for the Hyosung Rapier 450 Quad. This ATV model is powered by a Single cylinder, four-stroke engine with 448.80 ccm (27.39 cubic inches) of actual displacement before 12.0:1 compression. Fueling is metered via Carburettor allowing this machine to produce its 50.00 HP (36.5 kW) horsepower and 47.64 Nm (4.9 kgf-m or 35.1 ft.lbs) torque. According to our records engine heat of the Hyosung Rapier 450 Quad is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 175/75-10 and the rear is 255/55-9 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Hyosung Rapier 450 Quad was launched in 2011, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
