2012 Kawasaki KVF360 4x4 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2012 Kawasaki KVF360 4x4.

Basic Specs

Year2012
MakeKawasaki
ModelKawasaki KVF360 4x4
TypeATV
Cost

Engine

Displacement362.00 ccm (22.09 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression8.3:1
Bore/Stroke80.0 x 72.0 mm (3.1 x 2.8 inches)
Valves/Cylinder2
FuelingCarburettor
IgnitionDigital DC-CDI
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox
Final DriveShaft drive (cardan)
Clutch
DrivelineCVT with reverse. Gear Shaft (Selectable 4WD/2WD) final drive.

Performance

Horespower21.05 HP (15.4 kW)
Torque26.10 Nm (2.7 kgf-m or 19.3 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity13.50 litres (3.57 gallons)
Emissions

Chassis

Frame Type
Rake4.5°
Trail15 mm (0.6 inches)
Front SuspensionMacPherson strut
Front Travel170 mm (6.7 inches)
Rear SuspensionSwingarm with single shock absorber
Rear Travel180 mm (7.1 inches)
Seat
Seat Height904 mm (35.6 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,175 mm (46.3 inches)
Total Length2,065 mm (81.3 inches)
Total Width1,205 mm (47.4 inches)
Ground Clearance250 mm (9.8 inches)
Wheelbase1,285 mm (50.6 inches)
Dry Weight274.5 kg (605.2 pounds)
Wet Weight294.0 kg (648.2 pounds)

Wheels & Brakes

Front Tire/Tyre25/8-12
Rear Tire/Tyre25/10-12
Front BrakesDouble disc
Front Brake Diameter166 mm (6.5 inches)
Rear BrakesSealed multidisc
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Kawasaki KVF360 4x4. This ATV model is powered by a Single cylinder, four-stroke engine with 362.00 ccm (22.09 cubic inches) of actual displacement before 8.3:1 compression. Fueling is metered via Carburettor allowing this machine to produce its 21.05 HP (15.4 kW) horsepower and 26.10 Nm (2.7 kgf-m or 19.3 ft.lbs) torque. According to our records engine heat of the Kawasaki KVF360 4x4 is moderated by Air. You'll need to get familiar with the transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 25/8-12 and the rear is 25/10-12 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Sealed multidisc rear brakes. The Kawasaki KVF360 4x4 was launched in 2012, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
