2012 KTM 990 Super Duke R Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2012 KTM 990 Super Duke R.

Basic Specs

Year2012
MakeKTM
ModelKTM 990 Super Duke R
Cost

Engine

Displacement999.00 ccm (60.96 cubic inches)
Type75° V-twin
DetailsV2, four-stroke
Max RPM
Compression11.5:1
Bore/Stroke101.0 x 62.4 mm (4.0 x 2.5 inches)
Valves/Cylinder
FuelingInjection. Keihin EFI with EPT (Electric Power Throttle)
IgnitionContactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Exhaust
LubricationDry-sump lubrication with 2 rotor pumps
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchWet multi-disc clutch / hydraulically operated
Driveline16:38. Primary drive: 35:67

Performance

Horespower123.00 HP (89.8 kW)
Torque100.00 Nm (10.2 kgf-m or 73.8 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity18.50 litres (4.89 gallons)
Emissions

Chassis

Frame TypeTubular space frame made from chrome molybdenum steel, powder-coated
Rake22.7°
Trail101 mm (4.0 inches)
Front SuspensionWP Suspension Up Side Down 4860 ROMA PA
Front Travel135 mm (5.3 inches)
Rear SuspensionWP Suspension 4618 BAVP DCC
Rear Travel150 mm (5.9 inches)
Seat
Seat Height850 mm (33.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance150 mm (5.9 inches)
Wheelbase1,450 mm (57.1 inches)
Dry Weight186.0 kg (410.1 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-17
Rear Tire/Tyre180/55-ZR17
Front BrakesDouble disc. Radially mounted four-piston brake calipers; floating brake discs
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. Two-piston brake caliper; fixed brake disc
Rear Brake Diameter240 mm (9.4 inches)
Wheels

Comments

It appears you're interested in specifications for the KTM 990 Super Duke R. This Naked bike model is powered by a 75° V-twin V2, four-stroke engine with 999.00 ccm (60.96 cubic inches) of actual displacement before 11.5:1 compression. Fueling is metered via Injection. Keihin EFI with EPT (Electric Power Throttle) allowing this machine to produce its 123.00 HP (89.8 kW) horsepower and 100.00 Nm (10.2 kgf-m or 73.8 ft.lbs) torque. According to our records engine heat of the KTM 990 Super Duke R is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-17 and the rear is 180/55-ZR17 . The entire package is supported by the frame, Tubular space frame made from chrome molybdenum steel, powder-coated. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Radially mounted four-piston brake calipers; floating brake discs front brakes and Single disc. Two-piston brake caliper; fixed brake disc rear brakes. The KTM 990 Super Duke R was launched in 2012, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
