2013 Harley-Davidson Sportster 883 Roadster Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2013 Harley-Davidson Sportster 883 Roadster.

Basic Specs

Year2013
MakeHarley-Davidson
ModelHarley-Davidson Sportster 883 Roadster
Cost Euro 8495. UK £ 6895. Prices depend on country, taxes, accessories, etc.

Engine

Displacement883.00 ccm (53.88 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression9.0:1
Bore/Stroke76.2 x 96.8 mm (3.0 x 3.8 inches)
Valves/Cylinder
FuelingInjection. Electronic Sequential Port Fuel Injection (ESPFI)
Ignition
ExhaustE Type 7
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchMulti-plate with diaphragm spring in oil bath
DrivelineChain, 57/34 ratio

Performance

Horespower
Torque70.00 Nm (7.1 kgf-m or 51.6 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity12.50 litres (3.30 gallons)
Emissions

Chassis

Frame Type
Rake29.7°
Trail112 mm (4.4 inches)
Front Suspension
Front Travel
Rear Suspension
Rear Travel
Seat
Seat Height760 mm (29.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,245 mm (88.4 inches)
Total Width
Ground Clearance141 mm (5.6 inches)
Wheelbase1,520 mm (59.8 inches)
Dry Weight251.0 kg (553.4 pounds)
Wet Weight260.0 kg (573.2 pounds)

Wheels & Brakes

Front Tire/Tyre100/90-B19
Rear Tire/Tyre150/80-B16
Front BrakesDouble disc
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter
WheelsBlack, 13-Spoke Cast Aluminum

Comments

It appears you're interested in specifications for the Harley-Davidson Sportster 883 Roadster. This Custom / cruiser model is powered by a V2, four-stroke engine with 883.00 ccm (53.88 cubic inches) of actual displacement before 9.0:1 compression. Fueling is metered via Injection. Electronic Sequential Port Fuel Injection (ESPFI) allowing this machine to produce its horsepower and 70.00 Nm (7.1 kgf-m or 51.6 ft.lbs) torque. According to our records engine heat of the Harley-Davidson Sportster 883 Roadster is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 100/90-B19 and the rear is 150/80-B16 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Harley-Davidson Sportster 883 Roadster was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
