These are the known mechanical and performance specifications for your 2013 Honda FourTrax Foreman 4x4.
Basic Specs
Year2013
MakeHonda
ModelHonda FourTrax Foreman 4x4
TypeATV
CostUS$ 6999. Prices depend on country, taxes, accessories, etc.
Engine
Displacement475.00 ccm (28.98 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.5:1
Bore/Stroke92.0 x 71.5 mm (3.6 x 2.8 inches)
Valves/Cylinder
FuelingCarburettor. Keihin® 36mm throttle body
IgnitionFull-transistorized type with electronic advance
Exhaust
LubricationDry sump
CoolingLiquid
Drivetrain
Gearbox5-speed
Final DriveShaft drive (cardan)
ClutchAutomatic
DrivelineDirect front and rear driveshafts with TraxLok® and torque-sensitive front differential
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity15.14 litres (4.00 gallons)
Emissions
Chassis
Frame Type
Rake
Trail
Front SuspensionIndependent double-wishbone
Front Travel170 mm (6.7 inches)
Rear SuspensionSwingarm with single shock
Rear Travel175 mm (6.9 inches)
Seat
Seat Height881 mm (34.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,196 mm (47.1 inches)
Total Length2,126 mm (83.7 inches)
Total Width1,204 mm (47.4 inches)
Ground Clearance193 mm (7.6 inches)
Wheelbase1,280 mm (50.4 inches)
Dry Weight
Wet Weight284.0 kg (626.0 pounds)
Wheels & Brakes
Front Tire/Tyre25/8-12
Rear Tire/Tyre25/10-12
Front BrakesDouble disc. Hydraulic.
Front Brake Diameter196 mm (7.7 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter180 mm (7.1 inches)
Wheels
Comments
Model ID: TRX500FM
