2013 Honda VTR Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2013 Honda VTR.

Basic Specs

Year2013
MakeHonda
ModelHonda VTR
TypeNaked bike
Cost
Service Manual
Classic Service Manual
Electric Service Manual

Engine

Displacement249.00 ccm (15.19 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression11.0:1
Bore/Stroke60.0 x 44.1 mm (2.4 x 1.7 inches)
Valves/Cylinder
FuelingInjection. PGM-FI
Ignition
Exhaust
Lubrication
CoolingLiquid
Spark Plugs

Drivetrain

Gearbox5-speed
Final DriveChain
ClutchWet multi-plate coil spring
DrivelineConstant mesh
Chain Clutch Plates

Performance

Horespower29.50 HP (21.5 kW)
Torque22.00 Nm (2.2 kgf-m or 16.2 ft.lbs)
Top Speed
K&N Air Filter Slip-on Exhaust

Fuel Economy & Polution

Fuel Consumption2.50 litres/100 km (40.0 km/l or 94.09 mpg)
Fuel Capacity12.00 litres (3.17 gallons)
Emissions58.0 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel Bottles & Cans

Chassis

Frame TypeDiamond
Rake25.5°
Trail90 mm (3.5 inches)
Front SuspensionTelescopic fork
Front Travel
Rear SuspensionSwing arm
Rear Travel
SeatTwo person seat
Seat Height725 mm (28.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,055 mm (41.5 inches)
Total Length2,080 mm (81.9 inches)
Total Width
Ground Clearance155 mm (6.1 inches)
Wheelbase1,405 mm (55.3 inches)
Dry Weight161.0 kg (354.9 pounds)
Wet Weight
Seats & Covers Lowering Kits Titanium

Wheels & Brakes

Front Tire/Tyre110/70-17
Rear Tire/Tyre140/70-17
Front BrakesSingle disc. Hydraulic
Front Brake Diameter
Rear BrakesSingle disc. Hydraulic
Rear Brake Diameter
Wheels
Front Brakes Pads Rear Brake Pads Front Tire Rear Tire

Comments

It appears you're interested in specifications for the Honda VTR. This Naked bike model is powered by a V2, four-stroke engine with 249.00 ccm (15.19 cubic inches) of actual displacement before 11.0:1 compression. Fueling is metered via Injection. PGM-FI allowing this machine to produce its 29.50 HP (21.5 kW) horsepower and 22.00 Nm (2.2 kgf-m or 16.2 ft.lbs) torque. According to our records engine heat of the Honda VTR is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 110/70-17 and the rear is 140/70-17 . The entire package is supported by the frame, Diamond. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Hydraulic front brakes and Single disc. Hydraulic rear brakes. The Honda VTR was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Sold in the Asian market.
