2014 BMW R nine T Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2014 BMW R nine T.

Basic Specs

Year2014
MakeBMW
ModelBMW R nine T
Cost Euro 11600. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1170.00 ccm (71.39 cubic inches)
Type
DetailsTwo cylinder boxer, two-stroke
Max RPM
Compression12.0:1
Bore/Stroke101.0 x 73.0 mm (4.0 x 2.9 inches)
Valves/Cylinder
FuelingInjection. Electronic intake pipe injection Closed-loop 3-way catalytic converter, emission standard EU-3
Ignition
Exhaust
Lubrication
CoolingOil & air

Drivetrain

Gearbox6-speed
Final DriveShaft drive (cardan)
ClutchSingle dry plate clutch, hydraulically operated
DrivelineConstant mesh

Performance

Horespower108.62 HP (79.3 kW)
Torque119.00 Nm (12.1 kgf-m or 87.8 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption4.50 litres/100 km (22.2 km/l or 52.27 mpg)
Fuel Capacity18.00 litres (4.76 gallons)
Emissions104.4 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeFour-section frame consisting of one front and three rear sections, load-bearing engine-gearbox unit, removable pillion frame for single ride use
Rake25.5°
Trail103 mm (4.0 inches)
Front SuspensionUpside-Down telescopic fork with 46 mm diameter
Front Travel120 mm (4.7 inches)
Rear SuspensionAst aluminium single-sided swing arm with BMW Motorrad Paralever
Rear Travel135 mm (5.3 inches)
Seat
Seat Height785 mm (30.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,265 mm (49.8 inches)
Total Length2,220 mm (87.4 inches)
Total Width890 mm (35.0 inches)
Ground Clearance
Wheelbase1,476 mm (58.1 inches)
Dry Weight
Wet Weight222.0 kg (489.4 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre80/55-ZR17
Front BrakesDouble disc. Floating discs. Four-piston calipers.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. Floating disc. Two-piston calipers.
Rear Brake Diameter265 mm (10.4 inches)
WheelsSpoke wheels

Comments

It appears you're interested in specifications for the BMW R nine T. This Naked bike model is powered by a Two cylinder boxer, two-stroke engine with 1170.00 ccm (71.39 cubic inches) of actual displacement before 12.0:1 compression. Fueling is metered via Injection. Electronic intake pipe injection Closed-loop 3-way catalytic converter, emission standard EU-3 allowing this machine to produce its 108.62 HP (79.3 kW) horsepower and 119.00 Nm (12.1 kgf-m or 87.8 ft.lbs) torque. According to our records engine heat of the BMW R nine T is moderated by Oil & air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 80/55-ZR17 . The entire package is supported by the frame, Four-section frame consisting of one front and three rear sections, load-bearing engine-gearbox unit, removable pillion frame for single ride use. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Floating discs. Four-piston calipers. front brakes and Single disc. Floating disc. Two-piston calipers. rear brakes. The BMW R nine T was launched in 2014, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
