These are the known mechanical and performance specifications for your 2014 Harley-Davidson Street Glide Special.
Basic Specs
Year2014
MakeHarley-Davidson
ModelHarley-Davidson Street Glide Special
TypeTouring
CostUS$ 22499. Prices depend on country, taxes, accessories, etc.
Engine
Displacement1687.97 ccm (103.00 cubic inches)
TypeTwin Cam 103™ with Integrated Oil-Cooler
DetailsV2, four-stroke
Max RPM
Compression9.7:1
Bore/Stroke98.4 x 111.3 mm (3.9 x 4.4 inches)
Valves/Cylinder
FuelingInjection. ESPFI
Ignition
ExhaustChrome, 2-1-2 dual exhaust with tapered mufflers
LubricationDry sump
CoolingOil & air
Drivetrain
Gearbox6-speed
Final DriveBelt
ClutchMulti-plate with diaphragm spring in oil bath
DrivelineChain, 34/46 ratio
Performance
Horespower
Torque135.60 Nm (13.8 kgf-m or 100.0 ft.lbs)
Top Speed
Fuel Economy & Polution
Fuel Consumption5.60 litres/100 km (17.9 km/l or 42.00 mpg)
Fuel Capacity22.71 litres (6.00 gallons)
Emissions129.9 CO2 g/km. (CO2 - Carbon dioxide emission)
Chassis
Frame Type
Rake26.0°
Trail170 mm (6.7 inches)
Front Suspension
Front Travel
Rear Suspension
Rear Travel
Seat
Seat Height663 mm (26.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,451 mm (96.5 inches)
Total Width
Ground Clearance119 mm (4.7 inches)
Wheelbase1,613 mm (63.5 inches)
Dry Weight355.2 kg (783.0 pounds)
Wet Weight367.9 kg (811.0 pounds)
Wheels & Brakes
Front Tire/Tyre130/70-BW18
Rear Tire/Tyre180/65-BW16
Front BrakesDouble disc. 4-piston
Front Brake Diameter
Rear BrakesSingle disc. 2-piston
Rear Brake Diameter
WheelsEnforcer Cast Aluminum
Comments
Windshield
