2014 Honda CTX700N DCT ABS Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2014 Honda CTX700N DCT ABS.

Basic Specs

Year2014
MakeHonda
ModelHonda CTX700N DCT ABS
CostUS$ 7999. Prices depend on country, taxes, accessories, etc.

Engine

Displacement670.00 ccm (40.88 cubic inches)
Type
DetailsTwin, four-stroke
Max RPM
Compression10.7:1
Bore/Stroke73.0 x 80.0 mm (2.9 x 3.1 inches)
Valves/Cylinder4
FuelingInjection. PGM-FI with 36mm throttle body
IgnitionDigital transistorized with electronicadvance
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity12.40 litres (3.28 gallons)
Emissions

Chassis

Frame Type
Rake27.7°
Trail114 mm (4.5 inches)
Front Suspension41mm fork, 4.2 inches travel
Front Travel107 mm (4.2 inches)
Rear SuspensionPro-Link single shock, 4.3 inches travel
Rear Travel110 mm (4.3 inches)
Seat
Seat Height720 mm (28.3 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,155 mm (45.5 inches)
Total Length2,255 mm (88.8 inches)
Total Width855 mm (33.7 inches)
Ground Clearance130 mm (5.1 inches)
Wheelbase1,530 mm (60.2 inches)
Dry Weight
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-17
Rear Tire/Tyre160/60-17
Front BrakesSingle disc. ABS. Two-piston calipers.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. ABS. Single-piston caliper.
Rear Brake Diameter240 mm (9.4 inches)
Wheels

Comments

It appears you're interested in specifications for the Honda CTX700N DCT ABS. This Custom / cruiser model is powered by a Twin, four-stroke engine with 670.00 ccm (40.88 cubic inches) of actual displacement before 10.7:1 compression. Fueling is metered via Injection. PGM-FI with 36mm throttle body allowing this machine to produce its horsepower and torque. According to our records engine heat of the Honda CTX700N DCT ABS is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-17 and the rear is 160/60-17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. ABS. Two-piston calipers. front brakes and Single disc. ABS. Single-piston caliper. rear brakes. The Honda CTX700N DCT ABS was launched in 2014, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model ID: CTX700ND. Automatic Dual Clutch Transmission and Honda ABS.
