2014 Husqvarna TC250 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2014 Husqvarna TC250.

Basic Specs

Year2014
MakeHusqvarna
ModelHusqvarna TC250
Cost

Engine

Displacement249.50 ccm (15.22 cubic inches)
TypeReed valves
DetailsSingle cylinder, two-stroke
Max RPM
Compression
Bore/Stroke66.4 x 72.0 mm (2.6 x 2.8 inches)
Valves/Cylinder
FuelingInjection. Keihin Digital Fuel Injection
Ignition
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveChain
ClutchMulti plate, hydraulic operation
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity7.50 litres (1.98 gallons)
Emissions

Chassis

Frame TypeCentral tube frame made of chrome molybdenum steel tubing
Rake26.5°
Trail
Front SuspensionWP Suspension Up Side Down
Front Travel300 mm (11.8 inches)
Rear SuspensionWP Monoshock with linkage
Rear Travel317 mm (12.5 inches)
Seat
Seat Height992 mm (39.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance385 mm (15.2 inches)
Wheelbase1,480 mm (58.3 inches)
Dry Weight97.8 kg (215.6 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre80/100-21
Rear Tire/Tyre120/90-19
Front BrakesSingle disc
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc
Rear Brake Diameter240 mm (9.4 inches)
Wheels

Comments

It appears you're interested in specifications for the Husqvarna TC250. This Cross / motocross model is powered by a Reed valves Single cylinder, two-stroke engine with 249.50 ccm (15.22 cubic inches) of actual displacement before compression. Fueling is metered via Injection. Keihin Digital Fuel Injection allowing this machine to produce its horsepower and torque. According to our records engine heat of the Husqvarna TC250 is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 80/100-21 and the rear is 120/90-19 . The entire package is supported by the frame, Central tube frame made of chrome molybdenum steel tubing. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The Husqvarna TC250 was launched in 2014, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
