These are the known mechanical and performance specifications for your 2014 KTM 250 SX-F.
Basic Specs
Engine
Displacement249.91 ccm (15.25 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke78.0 x 52.3 mm (3.1 x 2.1 inches)
Valves/Cylinder
Fueling
IgnitionContactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Exhaust
LubricationForced oil lubrication with 2 Eaton pumps
CoolingLiquid
Drivetrain
Gearbox5-speed
Final DriveChain
ClutchWet multi-disc clutch / hydraulically operated
Driveline13:48. Primary drive: 22:68.
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity7.50 litres (1.98 gallons)
Emissions
Chassis
Frame TypeCentral tube frame made of chrome molybdenum steel tubing
Rake26.5°
Trail
Front SuspensionWP Suspension Up Side Down 4860 MXMA CC
Front Travel300 mm (11.8 inches)
Rear SuspensionWP Suspension 5018 BAVP DCC
Rear Travel317 mm (12.5 inches)
Seat
Seat Height992 mm (39.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance376 mm (14.8 inches)
Wheelbase1,495 mm (58.9 inches)
Dry Weight102.8 kg (226.6 pounds)
Wet Weight
Wheels & Brakes
Front Tire/Tyre
Rear Tire/Tyre
Front BrakesSingle disc. Brake calipers on floating bearings
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc. Brake calipers on floating bearings
Rear Brake Diameter220 mm (8.7 inches)
Wheels
