These are the known mechanical and performance specifications for your 2015 Harley-Davidson Dyna Fat Bob Dark Custom.
Basic Specs
Year2015
MakeHarley-Davidson
ModelHarley-Davidson Dyna Fat Bob Dark Custom
TypeCustom / cruiser
CostUS$ 15699. Prices depend on country, taxes, accessories, etc.
Engine
Displacement1687.97 ccm (103.00 cubic inches)
TypeAir-cooled, Twin Cam 103™
DetailsV2, four-stroke
Max RPM
Compression9.6:1
Bore/Stroke98.4 x 111.3 mm (3.9 x 4.4 inches)
Valves/Cylinder
FuelingInjection. Electronic Sequential Port Fuel Injection
Ignition
ExhaustChrome, “Tommy Gun” 2-1-2 collector exhaust with dual mufflers
LubricationDry-sump
CoolingAir
Drivetrain
Gearbox6-speed
Final DriveBelt
ClutchMulti-plate with diaphragm spring in oil bath
DrivelineChain, 34/46 ratio primar drive
Performance
Horespower
Torque135.60 Nm (13.8 kgf-m or 100.0 ft.lbs)
Top Speed
Fuel Economy & Polution
Fuel Consumption5.60 litres/100 km (17.9 km/l or 42.00 mpg)
Fuel Capacity18.93 litres (5.00 gallons)
Emissions129.9 CO2 g/km. (CO2 - Carbon dioxide emission)
Chassis
Frame Type
Rake29.0°
Trail124 mm (4.9 inches)
Front Suspension
Front Travel
Rear Suspension
Rear Travel
Seat
Seat Height690 mm (27.2 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,400 mm (94.5 inches)
Total Width
Ground Clearance124 mm (4.9 inches)
Wheelbase1,621 mm (63.8 inches)
Dry Weight
Wet Weight320.2 kg (706.0 pounds)
Wheels & Brakes
Front Tire/Tyre130/90-B16
Rear Tire/Tyre180/70-B16
Front BrakesSingle disc. Optional ABS. 4-piston fixed
Front Brake Diameter
Rear BrakesSingle disc. Optional ABS. 2-piston torque-free floating
Rear Brake Diameter
WheelsGloss Black Cast Aluminum Wheel w/ Laser Etched Graphics
