2015 Honda CTX700 DCT ABS Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2015 Honda CTX700 DCT ABS.

Basic Specs

Year2015
MakeHonda
ModelHonda CTX700 DCT ABS
Cost

Engine

Displacement670.00 ccm (40.88 cubic inches)
Type
DetailsTwin, four-stroke
Max RPM
Compression10.7:1
Bore/Stroke73.0 x 80.0 mm (2.9 x 3.1 inches)
Valves/Cylinder4
FuelingInjection. PGM-FI with 36mm throttle body
IgnitionDigital transistorized with electronic advance
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption3.86 litres/100 km (25.9 km/l or 60.94 mpg)
Fuel Capacity12.00 litres (3.17 gallons)
Emissions89.6 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeDiamond-Shape Steel Frame
Rake27.7°
Trail114 mm (4.5 inches)
Front Suspension41mm fork, 4.2 inches travel
Front Travel
Rear SuspensionPro-Link single shock, 4.3 inches travel
Rear Travel
Seat
Seat Height719 mm (28.3 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,165 mm (45.9 inches)
Total Length2,255 mm (88.8 inches)
Total Width840 mm (33.1 inches)
Ground Clearance130 mm (5.1 inches)
Wheelbase1,529 mm (60.2 inches)
Dry Weight
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-17
Rear Tire/Tyre160/60-17
Front BrakesSingle disc. ABS. Two-piston calipers.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. ABS. Single-piston caliper.
Rear Brake Diameter240 mm (9.4 inches)
Wheels

Comments

It appears you're interested in specifications for the Honda CTX700 DCT ABS. This Sport touring model is powered by a Twin, four-stroke engine with 670.00 ccm (40.88 cubic inches) of actual displacement before 10.7:1 compression. Fueling is metered via Injection. PGM-FI with 36mm throttle body allowing this machine to produce its horsepower and torque. According to our records engine heat of the Honda CTX700 DCT ABS is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-17 and the rear is 160/60-17 . The entire package is supported by the frame, Diamond-Shape Steel Frame. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. ABS. Two-piston calipers. front brakes and Single disc. ABS. Single-piston caliper. rear brakes. The Honda CTX700 DCT ABS was launched in 2015, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model ID: CTX700ND. Dual Clutch Transmission and Honda ABS.
