2016 CF Moto CForce 800 25th Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 CF Moto CForce 800 25th.

Basic Specs

Year2016
MakeCF Moto
ModelCF Moto CForce 800 25th
TypeATV
Cost

Engine

Displacement800.00 ccm (48.82 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression10.3:1
Bore/Stroke91.0 x 65.1 mm (3.6 x 2.6 inches)
Valves/Cylinder
FuelingInjection. Delphi electronic Fuel Injection
IgnitionCDI
Exhaust
Lubrication
CoolingLiquid

Drivetrain

GearboxAutomatic
Final DriveBelt
Clutch
DrivelineCVT. Switchable 2WD/4WD.

Performance

Horespower63.00 HP (46.0 kW)
Torque72.00 Nm (7.3 kgf-m or 53.1 ft.lbs)
Top Speed105.0 km/h (65.2 mph)

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity23.00 litres (6.08 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionDual A-arm
Front Travel
Rear SuspensionDual A-arm
Rear Travel
Seat
Seat Height880 mm (34.6 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,340 mm (52.8 inches)
Total Length2,310 mm (90.9 inches)
Total Width1,180 mm (46.5 inches)
Ground Clearance270 mm (10.6 inches)
Wheelbase1,480 mm (58.3 inches)
Dry Weight403.0 kg (888.5 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre25/9-12
Rear Tire/Tyre26/9-14
Front BrakesDouble disc
Front Brake Diameter220 mm (8.7 inches)
Rear BrakesSingle disc
Rear Brake Diameter150 mm (5.9 inches)
WheelsAluminum Alloy

Comments

It appears you're interested in specifications for the CF Moto CForce 800 25th. This ATV model is powered by a V2, four-stroke engine with 800.00 ccm (48.82 cubic inches) of actual displacement before 10.3:1 compression. Fueling is metered via Injection. Delphi electronic Fuel Injection  allowing this machine to produce its 63.00 HP (46.0 kW) horsepower and 72.00 Nm (7.3 kgf-m or 53.1 ft.lbs) torque. According to our records engine heat of the CF Moto CForce 800 25th is moderated by Liquid. You'll need to get familiar with the Automatic transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 25/9-12 and the rear is 26/9-14 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The CF Moto CForce 800 25th was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Also called CFMoto CForce 800 25th Anniversary.
