2016 GAS GAS EC 300F Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 GAS GAS EC 300F.

Basic Specs

Year2016
MakeGAS GAS
ModelGAS GAS EC 300F
Cost

Engine

Displacement290.00 ccm (17.70 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke83.0 x 53.6 mm (3.3 x 2.1 inches)
Valves/Cylinder
FuelingCarburettor. Keihin fcr-mx37
IgnitionElectronic
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveChain
ClutchMultidisc in oil bath
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity6.30 litres (1.66 gallons)
Emissions

Chassis

Frame TypeChrom-Molybdenum frame with B-profil
Rake
Trail
Front SuspensionMarzocchi shiver inverted ø48 mm, closed cartridge
Front Travel305 mm (12.0 inches)
Rear SuspensionAluminium swingarm. Reiger Mono shock. Spring preload, rebound and compression high/low speed.
Rear Travel298 mm (11.7 inches)
Seat
Seat Height950 mm (37.4 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,260 mm (49.6 inches)
Total Length2,200 mm (86.6 inches)
Total Width830 mm (32.7 inches)
Ground Clearance
Wheelbase1,490 mm (58.7 inches)
Dry Weight108.0 kg (238.1 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre90/90-21
Rear Tire/Tyre140/80-18
Front BrakesSingle disc. Two-piston calipers.
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc. Single-piston caliper.
Rear Brake Diameter220 mm (8.7 inches)
WheelsExcel Aluminium spoke rim

Comments

It appears you're interested in specifications for the GAS GAS EC 300F. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 290.00 ccm (17.70 cubic inches) of actual displacement before compression. Fueling is metered via Carburettor. Keihin fcr-mx37 allowing this machine to produce its horsepower and torque. According to our records engine heat of the GAS GAS EC 300F is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 90/90-21 and the rear is 140/80-18 . The entire package is supported by the frame, Chrom-Molybdenum frame with B-profil. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Two-piston calipers. front brakes and Single disc. Single-piston caliper. rear brakes. The GAS GAS EC 300F was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Spanish bike. Model also called Gas Gas EC 300F Racing.
