2016 Honda Ape 50 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 Honda Ape 50.

Basic Specs

Year2016
MakeHonda
ModelHonda Ape 50
Cost

Engine

Displacement49.00 ccm (2.99 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.2:1
Bore/Stroke42.0 x 35.6 mm (1.7 x 1.4 inches)
Valves/Cylinder
Fueling
IgnitionFull transistor type battery ignition
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox5-speed
Final DriveChain
ClutchWet, multiplate
Driveline

Performance

Horespower3.62 HP (2.6 kW)
Torque3.60 Nm (0.4 kgf-m or 2.7 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity5.50 litres (1.45 gallons)
Emissions

Chassis

Frame TypeDiamond
Rake28.0°
Trail89 mm (3.5 inches)
Front SuspensionTelescopic fork
Front Travel
Rear SuspensionSwing arm
Rear Travel
SeatTwo-person seat
Seat Height715 mm (28.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,155 mm (45.5 inches)
Total Length1,719 mm (67.7 inches)
Total Width780 mm (30.7 inches)
Ground Clearance155 mm (6.1 inches)
Wheelbase1,185 mm (46.7 inches)
Dry Weight
Wet Weight84.0 kg (185.2 pounds)

Wheels & Brakes

Front Tire/Tyre120/80-12
Rear Tire/Tyre120/80-12
Front BrakesExpanding brake (drum brake)
Front Brake Diameter
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter
WheelsCast aluminium

Comments

It appears you're interested in specifications for the Honda Ape 50. This Minibike, sport model is powered by a Single cylinder, four-stroke engine with 49.00 ccm (2.99 cubic inches) of actual displacement before 9.2:1 compression. Fueling is metered via allowing this machine to produce its 3.62 HP (2.6 kW) horsepower and 3.60 Nm (0.4 kgf-m or 2.7 ft.lbs) torque. According to our records engine heat of the Honda Ape 50 is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/80-12 and the rear is 120/80-12 . The entire package is supported by the frame, Diamond. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Expanding brake (drum brake) front brakes and Expanding brake (drum brake) rear brakes. The Honda Ape 50 was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Sold in Japan and some other Asian countries.
