2016 Kawasaki Vulcan S Special Edition Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 Kawasaki Vulcan S Special Edition.

Basic Specs

Year2016
MakeKawasaki
ModelKawasaki Vulcan S Special Edition
Cost

Engine

Displacement649.00 ccm (39.60 cubic inches)
Type
DetailsTwin, four-stroke
Max RPM
Compression10.8:1
Bore/Stroke83.0 x 60.0 mm (3.3 x 2.4 inches)
Valves/Cylinder4
FuelingInjection. 38 mm x 2 with sub-throttles
IgnitionTCBI with digital advance
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchWet multi-disc, manual
Driveline

Performance

Horespower61.00 HP (44.5 kW)
Torque63.00 Nm (6.4 kgf-m or 46.5 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity14.00 litres (3.70 gallons)
Emissions

Chassis

Frame TypePerimeter, high-tensile steel
Rake31.0°
Trail119 mm (4.7 inches)
Front Suspension41mm telescopic fork
Front Travel130 mm (5.1 inches)
Rear SuspensionLay-down offset rear shock with linkage and adjustable preload
Rear Travel81 mm (3.2 inches)
Seat
Seat Height706 mm (27.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,100 mm (43.3 inches)
Total Length2,311 mm (91.0 inches)
Total Width881 mm (34.7 inches)
Ground Clearance130 mm (5.1 inches)
Wheelbase1,575 mm (62.0 inches)
Dry Weight
Wet Weight225.0 kg (496.0 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-18
Rear Tire/Tyre160/60-17
Front BrakesDouble disc. Two-piston calipers. Optional ABS.
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. Single-piston caliper. Optional ABS.
Rear Brake Diameter250 mm (9.8 inches)
Wheels

Comments

It appears you're interested in specifications for the Kawasaki Vulcan S Special Edition. This Custom / cruiser model is powered by a Twin, four-stroke engine with 649.00 ccm (39.60 cubic inches) of actual displacement before 10.8:1 compression. Fueling is metered via Injection. 38 mm x 2 with sub-throttles allowing this machine to produce its 61.00 HP (44.5 kW) horsepower and 63.00 Nm (6.4 kgf-m or 46.5 ft.lbs) torque. According to our records engine heat of the Kawasaki Vulcan S Special Edition is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-18 and the rear is 160/60-17 . The entire package is supported by the frame, Perimeter, high-tensile steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Two-piston calipers. Optional ABS. front brakes and Single disc. Single-piston caliper. Optional ABS. rear brakes. The Kawasaki Vulcan S Special Edition was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Limited power version of 35 kW available. ABS adds 3 kg.
