2016 Piaggio BV 350 ABS Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 Piaggio BV 350 ABS.

Basic Specs

Year2016
MakePiaggio
ModelPiaggio BV 350 ABS
CostUS$ 6199. Prices depend on country, taxes, accessories, etc.

Engine

Displacement330.00 ccm (20.14 cubic inches)
TypeQuasar engine
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke78.0 x 69.0 mm (3.1 x 2.7 inches)
Valves/Cylinder4
FuelingInjection
Ignition
Exhaust
LubricationDry sump
CoolingLiquid

Drivetrain

GearboxAutomatic
Final DriveBelt
ClutchMulti-disc centrifuge in oil bath
DrivelineCVT with torque server

Performance

Horespower32.80 HP (23.9 kW)
Torque32.30 Nm (3.3 kgf-m or 23.8 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity13.00 litres (3.43 gallons)
Emissions

Chassis

Frame TypeTwin cradle tubes in high tensile steel
Rake
Trail
Front SuspensionTelescopic hydraulic fork with 35-­mm stanchions
Front Travel
Rear SuspensionDouble shock absorbers
Rear Travel
Seat
Seat Height787 mm (31.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,320 mm (52.0 inches)
Total Length2,115 mm (83.3 inches)
Total Width760 mm (29.9 inches)
Ground Clearance
Wheelbase1,560 mm (61.4 inches)
Dry Weight176.9 kg (390.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre110/70-16
Rear Tire/Tyre150/70-14
Front BrakesSingle disc. ABS. Three piston floating calliper
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. ABS. Dual piston floating calliper
Rear Brake Diameter260 mm (10.2 inches)
WheelsAluminium alloy

Comments

It appears you're interested in specifications for the Piaggio BV 350 ABS. This Scooter model is powered by a Quasar engine Single cylinder, four-stroke engine with 330.00 ccm (20.14 cubic inches) of actual displacement before compression. Fueling is metered via Injection allowing this machine to produce its 32.80 HP (23.9 kW) horsepower and 32.30 Nm (3.3 kgf-m or 23.8 ft.lbs) torque. According to our records engine heat of the Piaggio BV 350 ABS is moderated by Liquid. You'll need to get familiar with the Automatic transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 110/70-16 and the rear is 150/70-14 . The entire package is supported by the frame, Twin cradle tubes in high tensile steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. ABS. Three piston floating calliper front brakes and Single disc. ABS. Dual piston floating calliper rear brakes. The Piaggio BV 350 ABS was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
