2016 Suzuki GSX650F ABS Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 Suzuki GSX650F ABS.

Basic Specs

Year2016
MakeSuzuki
ModelSuzuki GSX650F ABS
Cost

Engine

Displacement656.00 ccm (40.03 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression11.5:1
Bore/Stroke65.5 x 48.7 mm (2.6 x 1.9 inches)
Valves/Cylinder4
FuelingInjection
IgnitionElectronic ignition (transistorised)
Exhaust
LubricationWet sump
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower84.00 HP (61.3 kW)
Torque62.00 Nm (6.3 kgf-m or 45.7 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity19.00 litres (5.02 gallons)
Emissions

Chassis

Frame TypeDouble cradle, steel
Rake26.0°
Trail108 mm (4.3 inches)
Front SuspensionKYB telescopic, coil spring, oil damped
Front Travel
Rear SuspensionLink type, coil spring, oil damped
Rear Travel
Seat
Seat Height790 mm (31.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,235 mm (48.6 inches)
Total Length2,130 mm (83.9 inches)
Total Width760 mm (29.9 inches)
Ground Clearance125 mm (4.9 inches)
Wheelbase1,470 mm (57.9 inches)
Dry Weight
Wet Weight245.0 kg (540.1 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre160/60-ZR17
Front BrakesDouble disc. ABS
Front Brake Diameter130 mm (5.1 inches)
Rear BrakesSingle disc. ABS
Rear Brake Diameter128 mm (5.0 inches)
Wheels

Comments

It appears you're interested in specifications for the Suzuki GSX650F ABS. This Allround model is powered by a In-line four, four-stroke engine with 656.00 ccm (40.03 cubic inches) of actual displacement before 11.5:1 compression. Fueling is metered via Injection allowing this machine to produce its 84.00 HP (61.3 kW) horsepower and 62.00 Nm (6.3 kgf-m or 45.7 ft.lbs) torque. According to our records engine heat of the Suzuki GSX650F ABS is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 160/60-ZR17 . The entire package is supported by the frame, Double cradle, steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS front brakes and Single disc. ABS rear brakes. The Suzuki GSX650F ABS was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
