Suzuki

2016 Suzuki LTF 250 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 Suzuki LTF 250.

Basic Specs

Year2016
MakeSuzuki
ModelSuzuki LTF 250
TypeATV
Cost
Service Manual
Classic Service Manual
Electric Service Manual

Engine

Displacement249.00 ccm (15.19 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.2:1
Bore/Stroke66.0 x 72.0 mm (2.6 x 2.8 inches)
Valves/Cylinder
FuelingCarburettor. Mikuni BS29
Ignition
Exhaust
Lubrication
CoolingAir
Spark Plugs

Drivetrain

Gearbox5-speed
Final DriveShaft drive (cardan)
Clutch
Driveline5-forward and 1-reverse. 2WD.
Shaft drive (cardan) Clutch Plates

Performance

Horespower
Torque
Top Speed
K&N Air Filter Slip-on Exhaust

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity10.60 litres (2.80 gallons)
Emissions
Fuel Bottles & Cans

Chassis

Frame TypeSteel tube
Rake
Trail
Front SuspensionIndependent, double wishbone, coil spring, oil damped
Front Travel140 mm (5.5 inches)
Rear SuspensionSwingarm type, coil spring, oil damped
Rear Travel140 mm (5.5 inches)
Seat
Seat Height785 mm (30.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,055 mm (41.5 inches)
Total Length1,870 mm (73.6 inches)
Total Width1,070 mm (42.1 inches)
Ground Clearance210 mm (8.3 inches)
Wheelbase1,144 mm (45.0 inches)
Dry Weight187.0 kg (412.3 pounds)
Wet Weight
Seats & Covers Lowering Kits Titanium

Wheels & Brakes

Front Tire/Tyre22/7-11
Rear Tire/Tyre22/10-9
Front BrakesDouble disc
Front Brake Diameter
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter
Wheels
Front Brakes Pads Rear Brake Pads Front Tire Rear Tire

Comments

It appears you're interested in specifications for the Suzuki LTF 250. This ATV model is powered by a Single cylinder, four-stroke engine with 249.00 ccm (15.19 cubic inches) of actual displacement before 9.2:1 compression. Fueling is metered via Carburettor. Mikuni BS29 allowing this machine to produce its horsepower and torque. According to our records engine heat of the Suzuki LTF 250 is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 22/7-11 and the rear is 22/10-9 . The entire package is supported by the frame, Steel tube. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Expanding brake (drum brake) rear brakes. The Suzuki LTF 250 was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Sold in South-America.
