2017 Honda CB1100 RS Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2017 Honda CB1100 RS.

Basic Specs

Year2017
MakeHonda
ModelHonda CB1100 RS
Cost

Engine

Displacement1140.00 ccm (69.56 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression9.5:1
Bore/Stroke73.5 x 67.2 mm (2.9 x 2.6 inches)
Valves/Cylinder4
FuelingInjection. PGM-FI with automatic enrichment circuit, 32mm throttle bodies
IgnitionDigital transistorized with electronic advance
Exhaust
Lubrication
CoolingOil & air

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline#530 O-ring-sealed chain

Performance

Horespower88.51 HP (64.6 kW)
Torque91.00 Nm (9.3 kgf-m or 67.1 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity14.76 litres (3.90 gallons)
Emissions

Chassis

Frame TypeDouble steel cradle
Rake27.0°
Trail114 mm (4.5 inches)
Front Suspension41mm fork with spring preload adjustability
Front Travel107 mm (4.2 inches)
Rear SuspensionTwin shocks with spring preload adjustability
Rear Travel114 mm (4.5 inches)
Seat
Seat Height792 mm (31.2 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height11,000 mm (433.1 inches)
Total Length2,100 mm (82.7 inches)
Total Width800 mm (31.5 inches)
Ground Clearance130 mm (5.1 inches)
Wheelbase1,491 mm (58.7 inches)
Dry Weight
Wet Weight252.0 kg (555.6 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-R17
Rear Tire/Tyre180/55-R17
Front BrakesDouble disc. Floating discs. Four-piston calipers.
Front Brake Diameter296 mm (11.7 inches)
Rear BrakesSingle disc. Single-piston caliper.
Rear Brake Diameter256 mm (10.1 inches)
Wheels10-spoke diecast aluminium

Comments

It appears you're interested in specifications for the Honda CB1100 RS. This Classic model is powered by a In-line four, four-stroke engine with 1140.00 ccm (69.56 cubic inches) of actual displacement before 9.5:1 compression. Fueling is metered via Injection. PGM-FI with automatic enrichment circuit, 32mm throttle bodies allowing this machine to produce its 88.51 HP (64.6 kW) horsepower and 91.00 Nm (9.3 kgf-m or 67.1 ft.lbs) torque. According to our records engine heat of the Honda CB1100 RS is moderated by Oil & air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-R17 and the rear is 180/55-R17 . The entire package is supported by the frame, Double steel cradle. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Floating discs. Four-piston calipers. front brakes and Single disc. Single-piston caliper. rear brakes. The Honda CB1100 RS was launched in 2017, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
