2017 Kawasaki D-Tracker X Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2017 Kawasaki D-Tracker X.

Basic Specs

Year2017
MakeKawasaki
ModelKawasaki D-Tracker X
Cost

Engine

Displacement249.00 ccm (15.19 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke72.0 x 61.2 mm (2.8 x 2.4 inches)
Valves/Cylinder4
FuelingInjection. Keihin
IgnitionDC-CDI
Exhaust
LubricationForced lubrication, wet sump
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchWet multi-disc
Driveline

Performance

Horespower24.14 HP (17.6 kW)
Torque21.00 Nm (2.1 kgf-m or 15.5 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity7.70 litres (2.03 gallons)
Emissions

Chassis

Frame TypeTubular, Semi-double cradle
Rake25.5°
Trail92 mm (3.6 inches)
Front SuspensionTelescopic fork
Front Travel
Rear SuspensionSwingarm (Uni-trak)
Rear Travel
Seat
Seat Height860 mm (33.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,125 mm (44.3 inches)
Total Length2,130 mm (83.9 inches)
Total Width795 mm (31.3 inches)
Ground Clearance225 mm (8.9 inches)
Wheelbase1,420 mm (55.9 inches)
Dry Weight138.0 kg (304.2 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre110/70-17
Rear Tire/Tyre130/70-17
Front BrakesSingle disc. Dual piston calliper
Front Brake Diameter240 mm (9.4 inches)
Rear BrakesSingle disc
Rear Brake Diameter190 mm (7.5 inches)
WheelsWire spoked

Comments

It appears you're interested in specifications for the Kawasaki D-Tracker X. This Super motard model is powered by a Single cylinder, four-stroke engine with 249.00 ccm (15.19 cubic inches) of actual displacement before compression. Fueling is metered via Injection. Keihin allowing this machine to produce its 24.14 HP (17.6 kW) horsepower and 21.00 Nm (2.1 kgf-m or 15.5 ft.lbs) torque. According to our records engine heat of the Kawasaki D-Tracker X is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 110/70-17 and the rear is 130/70-17 . The entire package is supported by the frame, Tubular, Semi-double cradle. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Dual piston calliper front brakes and Single disc rear brakes. The Kawasaki D-Tracker X was launched in 2017, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
