2017 Suzuki GW250F Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2017 Suzuki GW250F.

Basic Specs

Year2017
MakeSuzuki
ModelSuzuki GW250F
TypeSport
CostUS$ 4499. Prices depend on country, taxes, accessories, etc.

Engine

Displacement248.00 ccm (15.13 cubic inches)
TypeBalancer shaft
DetailsTwin, four-stroke
Max RPM
Compression11.5:1
Bore/Stroke53.5 x 55.2 mm (2.1 x 2.2 inches)
Valves/Cylinder2
FuelingInjection
IgnitionElectronic, fully transistorized
Exhaust
LubricationWet sump
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
DrivelineConstant mesh

Performance

Horespower24.00 HP (17.5 kW)
Torque22.00 Nm (2.2 kgf-m or 16.2 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity13.25 litres (3.50 gallons)
Emissions

Chassis

Frame TypeSemi double-cradle
Rake
Trail
Front SuspensionTelescopic, coil spring, oil damped
Front Travel120 mm (4.7 inches)
Rear SuspensionSwingarm, coil spring, oil damped
Rear Travel120 mm (4.7 inches)
Seat
Seat Height780 mm (30.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,145 mm (84.4 inches)
Total Width760 mm (29.9 inches)
Ground Clearance165 mm (6.5 inches)
Wheelbase1,430 mm (56.3 inches)
Dry Weight
Wet Weight189.0 kg (416.7 pounds)

Wheels & Brakes

Front Tire/Tyre110/80-17
Rear Tire/Tyre140/70-17
Front BrakesSingle disc. Hydraulic
Front Brake Diameter
Rear BrakesSingle disc. Hydraulic
Rear Brake Diameter
WheelsCast aluminum wheels, 3-spoke

Comments

It appears you're interested in specifications for the Suzuki GW250F. This Sport model is powered by a Balancer shaft Twin, four-stroke engine with 248.00 ccm (15.13 cubic inches) of actual displacement before 11.5:1 compression. Fueling is metered via Injection allowing this machine to produce its 24.00 HP (17.5 kW) horsepower and 22.00 Nm (2.2 kgf-m or 16.2 ft.lbs) torque. According to our records engine heat of the Suzuki GW250F is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 110/80-17 and the rear is 140/70-17 . The entire package is supported by the frame, Semi double-cradle . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Hydraulic front brakes and Single disc. Hydraulic rear brakes. The Suzuki GW250F was launched in 2017, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Windscreen
