2018 BMW F 800 R Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2018 BMW F 800 R.

Basic Specs

Year2018
MakeBMW
ModelBMW F 800 R
Cost

Engine

Displacement798.00 ccm (48.69 cubic inches)
Type
DetailsTwin, four-stroke
Max RPM
Compression12.0:1
Bore/Stroke82.0 x 75.6 mm (3.2 x 3.0 inches)
Valves/Cylinder4
FuelingInjection. Electronic injection
Ignition
Exhaust
LubricationDry sump
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchMultiple-disc clutch in oil bath, mechanically operated
DrivelineEndless O-ring chain with shock damping in rear wheel hub

Performance

Horespower90.00 HP (65.7 kW)
Torque86.00 Nm (8.8 kgf-m or 63.4 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity15.00 litres (3.96 gallons)
Emissions

Chassis

Frame TypeBridge-type frame, cast aluminium
Rake26.0°
Trail100 mm (3.9 inches)
Front SuspensionUpside-down fork
Front Travel125 mm (4.9 inches)
Rear SuspensionDie-cast aluminium double-sided swing-arm, central spring strut, spring preload hydraulically and steplessly adjustable via handwheel, adjustable rebound damping
Rear Travel125 mm (4.9 inches)
Seat
Seat Height790 mm (31.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,235 mm (48.6 inches)
Total Length2,145 mm (84.4 inches)
Total Width860 mm (33.9 inches)
Ground Clearance
Wheelbase1,526 mm (60.1 inches)
Dry Weight
Wet Weight202.0 kg (445.3 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre180/55-ZR17
Front BrakesDouble disc. ABS. Floating discs. Four-piston calipers. Radially mounted.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. ABS. Floating disc. Single-piston caliper.
Rear Brake Diameter265 mm (10.4 inches)
WheelsCast aluminium

Comments

It appears you're interested in specifications for the BMW F 800 R. This Allround model is powered by a Twin, four-stroke engine with 798.00 ccm (48.69 cubic inches) of actual displacement before 12.0:1 compression. Fueling is metered via Injection. Electronic injection allowing this machine to produce its 90.00 HP (65.7 kW) horsepower and 86.00 Nm (8.8 kgf-m or 63.4 ft.lbs) torque. According to our records engine heat of the BMW F 800 R is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 180/55-ZR17 . The entire package is supported by the frame, Bridge-type frame, cast aluminium. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Floating discs. Four-piston calipers. Radially mounted. front brakes and Single disc. ABS. Floating disc. Single-piston caliper. rear brakes. The BMW F 800 R was launched in 2018, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
