2018 BMW R nineT Racer S Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2018 BMW R nineT Racer S.

Basic Specs

Year2018
MakeBMW
ModelBMW R nineT Racer S
Cost

Engine

Displacement1170.00 ccm (71.39 cubic inches)
TypeRadially aligned valves per cylinder, central balancer shaft
DetailsTwo cylinder boxer, four-stroke
Max RPM
Compression12.0:1
Bore/Stroke101.0 x 73.0 mm (4.0 x 2.9 inches)
Valves/Cylinder4
FuelingInjection. Electronic intake pipe injection
Ignition
ExhaustChrome
Lubrication
CoolingOil & air

Drivetrain

Gearbox6-speed
Final DriveShaft drive (cardan)
ClutchSingle dry plate clutch, hydraulically operated
DrivelineConstant mesh

Performance

Horespower110.00 HP (80.3 kW)
Torque116.00 Nm (11.8 kgf-m or 85.6 ft.lbs)
Top Speed200.0 km/h (124.3 mph)

Fuel Economy & Polution

Fuel Consumption5.30 litres/100 km (18.9 km/l or 44.38 mpg)
Fuel Capacity17.00 litres (4.49 gallons)
Emissions123.0 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeThree-section frame consisting of one front and two rear sections, load-bearing engine-
Rake26.4°
Trail104 mm (4.1 inches)
Front SuspensionTelescopic forks with 43 mm fixed-tube diameter
Front Travel125 mm (4.9 inches)
Rear SuspensionCast aluminium single swinging arm with BMW Motorrad Paralever
Rear Travel120 mm (4.7 inches)
Seat
Seat Height805 mm (31.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,105 mm (43.5 inches)
Total Length2,105 mm (82.9 inches)
Total Width920 mm (36.2 inches)
Ground Clearance
Wheelbase1,491 mm (58.7 inches)
Dry Weight
Wet Weight220.0 kg (485.0 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre180/55-ZR17
Front BrakesDouble disc. ABS. Four-piston calipers.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. ABS. Floating disc. Two-piston calipers.
Rear Brake Diameter265 mm (10.4 inches)
WheelsCross Spoke Wheels

Comments

It appears you're interested in specifications for the BMW R nineT Racer S. This Naked bike model is powered by a Radially aligned valves per cylinder, central balancer shaft Two cylinder boxer, four-stroke engine with 1170.00 ccm (71.39 cubic inches) of actual displacement before 12.0:1 compression. Fueling is metered via Injection. Electronic intake pipe injection allowing this machine to produce its 110.00 HP (80.3 kW) horsepower and 116.00 Nm (11.8 kgf-m or 85.6 ft.lbs) torque. According to our records engine heat of the BMW R nineT Racer S is moderated by Oil & air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 180/55-ZR17 . The entire package is supported by the frame, Three-section frame consisting of one front and two rear sections, load-bearing engine-. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Four-piston calipers. front brakes and Single disc. ABS. Floating disc. Two-piston calipers. rear brakes. The BMW R nineT Racer S was launched in 2018, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
