2019 Indian Springfield Dark Horse Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2019 Indian Springfield Dark Horse.

Basic Specs

ModelIndian Springfield Dark Horse
CostUS$ 21499. Prices depend on country, taxes, accessories, etc.


Displacement1811.00 ccm (110.51 cubic inches)
TypeThunder Stroke® 111 engine, blacked out
DetailsV2, four-stroke
Bore/Stroke101.0 x 113.0 mm (4.0 x 4.4 inches)
FuelingInjection. Closed Loop Sequential Port Fuel Injection
ExhaustSplit dual exhaust with cross-over


Final DriveBelt
ClutchWet multi-plate


Torque161.36 Nm (16.5 kgf-m or 119.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity20.80 litres (5.50 gallons)


Frame TypeCast Aluminum Frame with Integrated Air-Box
Trail133 mm (5.2 inches)
Front SuspensionTelescopic forks with air adjust
Front Travel119 mm (4.7 inches)
Rear SuspensionSingle shock
Rear Travel114 mm (4.5 inches)
SeatDual leather seat
Seat Height660 mm (26.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,176 mm (46.3 inches)
Total Length2,522 mm (99.3 inches)
Total Width1,000 mm (39.4 inches)
Ground Clearance142 mm (5.6 inches)
Wheelbase1,701 mm (67.0 inches)
Dry Weight349.0 kg (769.4 pounds)
Wet Weight360.0 kg (793.7 pounds)

Wheels & Brakes

Front Tire/Tyre130/90-B16
Rear Tire/Tyre180/60-B16
Front BrakesDouble disc. ABS. Floating discs. 4 piston caliper.
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. ABS. Floating disc. 2-piston caliper.
Rear Brake Diameter300 mm (11.8 inches)
WheelsCast aluminium wheels


It appears you're interested in specifications for the Indian Springfield Dark Horse. This Touring model is powered by a Thunder Stroke® 111 engine, blacked out V2, four-stroke engine with 1811.00 ccm (110.51 cubic inches) of actual displacement before 9.5:1 compression. Fueling is metered via Injection. Closed Loop Sequential Port Fuel Injection allowing this machine to produce its horsepower and 161.36 Nm (16.5 kgf-m or 119.0 ft.lbs) torque. According to our records engine heat of the Indian Springfield Dark Horse is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 130/90-B16 and the rear is 180/60-B16 . The entire package is supported by the frame, Cast Aluminum Frame with Integrated Air-Box. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Floating discs. 4 piston caliper. front brakes and Single disc. ABS. Floating disc. 2-piston caliper. rear brakes. The Indian Springfield Dark Horse was launched in 2019, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Windscreen. Cruise Control.
