2020 Harley-Davidson Iron 883 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Harley-Davidson Iron 883.

Basic Specs

Harley-Davidson Iron 883
ModelHarley-Davidson Iron 883
CostUS$ 8999. MSRP depends on country, taxes, accessories, etc.


Displacement883.0 ccm (53.88 cubic inches)
TypeBlack Evolution® engine
DetailsV2, four-stroke
Bore/Stroke76.2 x 96.8 mm (3.0 x 3.8 inches)
FuelingInjection. Electronic Sequential Port Fuel Injection (ESPFI)
ExhaustBlack exhaust headers and black mufflers
LubricationDry sump


Final Drive
ClutchMulti-plate with diaphragm spring in oil bath


Horespower51.0 HP (37.2 kW) @ 6000 RPM
Torque73.0 Nm (7.4 kgf-m or 53.8 ft.lbs) @ 3750 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption4.61 litres/100 km (21.7 km/l or 51.02 mpg)
Fuel Capacity12.50 litres (3.30 US gallons)
Emissions107.0 CO2 g/km. (CO2 - Carbon dioxide emission)


Frame Type
Rake30.0 deg
Trail117 mm (4.6 inches)
Front SuspensionTelescopic fork
Front Travel
Rear SuspensionTwin shocks.
Rear Travel
Seat Height653 mm (25.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2185 mm (86.0 inches)
Total Width
Ground Clearance140 mm (5.5 inches)
Wheelbase1515 mm (59.6 inches)
Dry Weight247.0 kg (544.5 pounds)
Wet Weight256.0 kg (564.4 pounds)

Wheels & Brakes

Front Tire/Tyre100/90-B19
Rear Tire/Tyre150/80-B16
Front BrakesSingle disc. Optional ABS, dual piston
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. Optional ABS, dual piston
Rear Brake Diameter300 mm (11.8 inches)
WheelsBlack 9 Spoke with Machined Highlights


It appears you're interested in specifications for the Harley-Davidson Iron 883. This Custom / cruiser model is powered by a Black Evolution® engine V2, four-stroke engine with 883.0 ccm (53.88 cubic inches) of actual displacement before 9.0:1 compression. Fueling is metered via Injection. Electronic Sequential Port Fuel Injection (ESPFI) allowing this machine to produce its 51.0 HP (37.2 kW) @ 6000 RPM horsepower and 73.0 Nm (7.4 kgf-m or 53.8 ft.lbs) @ 3750 RPM torque. According to our records engine heat of the Harley-Davidson Iron 883 is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 100/90-B19 and the rear is 150/80-B16 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Optional ABS, dual piston front brakes and Single disc. Optional ABS, dual piston rear brakes. The Harley-Davidson Iron 883 was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
