These are the known mechanical and performance specifications for your 2020 Honda FourTrax Rancher.
Basic Specs
Year2020
MakeHonda
ModelHonda FourTrax Rancher
TypeATV
CostUS$ 5499. MSRP depends on country, taxes, accessories, etc.
Engine
Displacement420.0 ccm (25.63 cubic inches)
TypeLongitudinally mounted
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.9:1
Bore/Stroke86.5 x 71.5 mm (3.4 x 2.8 inches)
Valves/Cylinder
FuelingInjection. Keihin 34mm throttle-body
IgnitionFull-transistorized type with electronic advance
Exhaust
LubricationWet sump
CoolingLiquid
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity14.76 litres (3.90 US gallons)
Emissions
Chassis
Frame Type
Rake
Trail
Front SuspensionIndependent double-wishbone
Front Travel160 mm (6.3 inches)
Rear SuspensionSwingarm with single shock
Rear Travel160 mm (6.3 inches)
Seat
Seat Height856 mm (33.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1173 mm (46.2 inches)
Total Length2103 mm (82.8 inches)
Total Width1204 mm (47.4 inches)
Ground Clearance183 mm (7.2 inches)
Wheelbase1270 mm (50.0 inches)
Dry Weight
Wet Weight263.1 kg (580.0 pounds)
Wheels & Brakes
Front Tire/Tyre24/8-12
Rear Tire/Tyre24/10-11
Front BrakesDouble disc
Front Brake Diameter190 mm (7.5 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter160 mm (6.3 inches)
Wheels
Comments
Model ID: TRX420TM1
