2020 Indian Challenger Limited Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Indian Challenger Limited.

Basic Specs

Indian Challenger Limited
Year2020
MakeIndian
ModelIndian Challenger Limited
Cost

Engine

Displacement1769.9 ccm (108.00 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression11.0:1
Bore/Stroke108.0 x 96.5 mm (4.3 x 3.8 inches)
Valves/Cylinder
FuelingInjection. Closed loop fuel Injection / 52mm dual bore
Ignition
ExhaustSplit Dual exhaust w/ Resonator
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final Drive
ClutchWet, Multi-Plate, Assist
Driveline

Performance

Horespower122.0 HP (89.1 kW)
Torque173.6 Nm (17.7 kgf-m or 128.0 ft.lbs) @ 3800 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity22.70 litres (6.00 US gallons)
Emissions

Chassis

Frame Type
Rake25.0 deg
Trail150 mm (5.9 inches)
Front SuspensionTelescopic forks with air adjustment
Front Travel130 mm (5.1 inches)
Rear SuspensionSingle Shock w/Hyd adjust
Rear Travel114 mm (4.5 inches)
SeatDual leather seat
Seat Height672 mm (26.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1429 mm (56.3 inches)
Total Length2501 mm (98.5 inches)
Total Width990 mm (39.0 inches)
Ground Clearance137 mm (5.4 inches)
Wheelbase1668 mm (65.7 inches)
Dry Weight365.0 kg (804.7 pounds)
Wet Weight381.0 kg (840.0 pounds)

Wheels & Brakes

Front Tire/Tyre130/60-B19
Rear Tire/Tyre180/60-R16
Front BrakesDouble disc. ABS. Floating discs. 4 piston caliper.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. ABS. Floating disc. 2-piston caliper.
Rear Brake Diameter298 mm (11.7 inches)
WheelsMetzeler Cruisetec tires

Comments

It appears you're interested in specifications for the Indian Challenger Limited. This Custom / cruiser model is powered by a V2, four-stroke engine with 1769.9 ccm (108.00 cubic inches) of actual displacement before 11.0:1 compression. Fueling is metered via Injection. Closed loop fuel Injection / 52mm dual bore allowing this machine to produce its 122.0 HP (89.1 kW) horsepower and 173.6 Nm (17.7 kgf-m or 128.0 ft.lbs) @ 3800 RPM torque. According to our records engine heat of the Indian Challenger Limited is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 130/60-B19 and the rear is 180/60-R16 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Floating discs. 4 piston caliper. front brakes and Single disc. ABS. Floating disc. 2-piston caliper. rear brakes. The Indian Challenger Limited was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
