2020 Indian Chieftain Elite Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Indian Chieftain Elite.

Basic Specs

Indian Chieftain Elite
Year2020
MakeIndian
ModelIndian Chieftain Elite
Cost

Engine

Displacement1901.0 ccm (116.00 cubic inches)
TypeThunder Stroke® 116 engine
DetailsV2, four-stroke
Max RPM
Compression11.0:1
Bore/Stroke103.2 x 113.0 mm (4.1 x 4.4 inches)
Valves/Cylinder
FuelingInjection. Closed loop fuel injection / 54 mm bore
Ignition
Exhaust
Lubrication
Cooling

Drivetrain

Gearbox6-speed
Final Drive
ClutchWet, multi-plate
Driveline

Performance

Horespower
Torque168.0 Nm (17.1 kgf-m or 123.9 ft.lbs) @ 2900 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity20.80 litres (5.50 US gallons)
Emissions

Chassis

Frame TypeCast aluminium
Rake25.0 deg
Trail150 mm (5.9 inches)
Front SuspensionTelescopic
Front Travel119 mm (4.7 inches)
Rear SuspensionSingle Shock w/air adjust
Rear Travel114 mm (4.5 inches)
SeatDual leather seat
Seat Height650 mm (25.6 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1385 mm (54.5 inches)
Total Length2506 mm (98.7 inches)
Total Width1000 mm (39.4 inches)
Ground Clearance130 mm (5.1 inches)
Wheelbase1668 mm (65.7 inches)
Dry Weight365.0 kg (804.7 pounds)
Wet Weight379.0 kg (835.6 pounds)

Wheels & Brakes

Front Tire/Tyre130/60-B19
Rear Tire/Tyre180/60-R16
Front BrakesDouble disc. ABS. Floating discs. 4 piston caliper.
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. ABS. Floating disc. 2-piston caliper.
Rear Brake Diameter300 mm (11.8 inches)
Wheels

Comments

It appears you're interested in specifications for the Indian Chieftain Elite. This Custom / cruiser model is powered by a Thunder Stroke® 116 engine V2, four-stroke engine with 1901.0 ccm (116.00 cubic inches) of actual displacement before 11.0:1 compression. Fueling is metered via Injection. Closed loop fuel injection / 54 mm bore allowing this machine to produce its horsepower and 168.0 Nm (17.1 kgf-m or 123.9 ft.lbs) @ 2900 RPM torque. According to our records engine heat of the Indian Chieftain Elite is moderated by . You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 130/60-B19 and the rear is 180/60-R16 . The entire package is supported by the frame, Cast aluminium. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Floating discs. 4 piston caliper. front brakes and Single disc. ABS. Floating disc. 2-piston caliper. rear brakes. The Indian Chieftain Elite was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Selectable Ride Modes. Small windscreen. 7´ Touchscreen. Tire Pressure Monitoring. 100 Watt Stereo with AM/FM Bluetooth and Smartphone Compatible Input. Cruise Control. Keyless Ignition.
