2020 KTM 125 Duke Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 KTM 125 Duke.

Basic Specs

KTM 125 Duke
Year2020
MakeKTM
ModelKTM 125 Duke
Cost

Engine

Displacement125.0 ccm (7.63 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke58.0 x 47.2 mm (2.3 x 1.9 inches)
Valves/Cylinder
FuelingInjection
IgnitionContactless, controlled, fully electronic ignition system with digital ignition timing adjustment, type Kokusan
Exhaust
LubricationWet sump
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
ClutchWet multi-disc clutch, mechanically actuated
Driveline5/8 - x - 1/4 (520) O Ring. Primary drive: 22:72.

Performance

Horespower15.0 HP (10.9 kW)
Torque12.0 Nm (1.2 kgf-m or 8.9 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption2.42 litres/100 km (41.3 km/l or 97.20 mpg)
Fuel Capacity13.40 litres (3.54 US gallons)
Emissions56.1 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeSteel trellis frame, powder coated
Rake25.0 deg
Trail
Front SuspensionWP upside-down Ø 43 mm
Front Travel142 mm (5.6 inches)
Rear SuspensionWP Monoshock
Rear Travel150 mm (5.9 inches)
Seat
Seat Height830 mm (32.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance175 mm (6.9 inches)
Wheelbase1357 mm (53.4 inches)
Dry Weight139.0 kg (306.4 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre110-17
Rear Tire/Tyre150-17
Front BrakesSingle disc. ABS. Four-pot brake caliper
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. ABS. One-pot brake caliper, floating brake
Rear Brake Diameter230 mm (9.1 inches)
Wheels

Comments

It appears you're interested in specifications for the KTM 125 Duke. This Naked bike model is powered by a Single cylinder, four-stroke engine with 125.0 ccm (7.63 cubic inches) of actual displacement before compression. Fueling is metered via Injection allowing this machine to produce its 15.0 HP (10.9 kW) horsepower and 12.0 Nm (1.2 kgf-m or 8.9 ft.lbs) torque. According to our records engine heat of the KTM 125 Duke is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 110-17 and the rear is 150-17 . The entire package is supported by the frame, Steel trellis frame, powder coated. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. ABS. Four-pot brake caliper front brakes and Single disc. ABS. One-pot brake caliper, floating brake rear brakes. The KTM 125 Duke was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
