These are the known mechanical and performance specifications for your 2020 Suzuki KingQuad 500AXi.
Basic Specs
Year2020
MakeSuzuki
ModelSuzuki KingQuad 500AXi
TypeATV
CostUS$ 7549. MSRP depends on country, taxes, accessories, etc.
Engine
Displacement493.0 ccm (30.08 cubic inches)
TypeCounterbalancer shaft for smooth operation
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke87.5 x 82.0 mm (3.4 x 3.2 inches)
Valves/Cylinder4
FuelingInjection
Ignition
Exhaust
LubricationWet sump
CoolingLiquid
Drivetrain
GearboxAutomatic
Final Drive
ClutchSealed oil-bathed multi-disc
Driveline2WD, 4WD and differential-lock 4WD
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity17.50 litres (4.62 US gallons)
Emissions
Chassis
Frame Type
Rake
Trail
Front SuspensionIndependent, double wishbone, oil-damped. Spring preloaded, 5 way adjustable
Front Travel170 mm (6.7 inches)
Rear SuspensionIndependent, double wishbone, oil-damped. Spring preloaded, 5 way adjustable
Rear Travel196 mm (7.7 inches)
Seat
Seat Height920 mm (36.2 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1285 mm (50.6 inches)
Total Length2150 mm (84.6 inches)
Total Width1215 mm (47.8 inches)
Ground Clearance260 mm (10.2 inches)
Wheelbase1285 mm (50.6 inches)
Dry Weight
Wet Weight315.0 kg (694.5 pounds)
Wheels & Brakes
Front Tire/Tyre25/8-12
Rear Tire/Tyre25/10-12
Front BrakesDouble disc
Front Brake Diameter
Rear BrakesSealed multidisc
Rear Brake Diameter
WheelsSteel wheels
Comments
Optional power steering (EPS). Accessories are available, including winches, windshield, front and rear bumpers, a quick-release snow plow, aluminum skid pans, rack extensions, utility box and more.
