2021 Indian Springfield Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2021 Indian Springfield.

Basic Specs

Indian Springfield
ModelIndian Springfield
CostUS$ 21999. MSRP depends on country, taxes, accessories, etc.


Displacement1811.0 ccm (110.51 cubic inches)
TypeThunder Stroke® 111 engine
DetailsV2, four-stroke
Bore/Stroke101.0 x 113.0 mm (4.0 x 4.4 inches)
FuelingInjection. Closed Loop Sequential Port Fuel Injection
ExhaustSplit dual exhaust with cross-over


Final Drive
ClutchWet multi-plate


Horespower92.0 HP (67.2 kW)
Torque161.6 Nm (16.5 kgf-m or 119.2 ft.lbs) @ 3000 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity20.80 litres (5.50 US gallons)


Frame TypeCast Aluminum Frame with Integrated Air-Box
Rake25.0 deg
Trail133 mm (5.2 inches)
Front SuspensionTelescopic forks with air adjust
Front Travel119 mm (4.7 inches)
Rear SuspensionSingle shock
Rear Travel114 mm (4.5 inches)
SeatDual leather seat
Seat Height660 mm (26.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1442 mm (56.8 inches)
Total Length2583 mm (101.7 inches)
Total Width1000 mm (39.4 inches)
Ground Clearance142 mm (5.6 inches)
Wheelbase1701 mm (67.0 inches)
Dry Weight362.0 kg (798.1 pounds)
Wet Weight376.0 kg (828.9 pounds)

Wheels & Brakes

Front Tire/Tyre130/80-B16
Rear Tire/Tyre180/60-B16
Front BrakesDouble disc. ABS. Floating discs. 4 piston caliper.
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. ABS. Floating disc. 2-piston caliper.
Rear Brake Diameter300 mm (11.8 inches)
WheelsHighlight Machine Tour wheels. Metzeler Cruisetec tires.


It appears you're interested in specifications for the Indian Springfield. This Touring model is powered by a Thunder Stroke® 111 engine V2, four-stroke engine with 1811.0 ccm (110.51 cubic inches) of actual displacement before 9.5:1 compression. Fueling is metered via Injection. Closed Loop Sequential Port Fuel Injection allowing this machine to produce its 92.0 HP (67.2 kW) horsepower and 161.6 Nm (16.5 kgf-m or 119.2 ft.lbs) @ 3000 RPM torque. According to our records engine heat of the Indian Springfield is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 130/80-B16 and the rear is 180/60-B16 . The entire package is supported by the frame, Cast Aluminum Frame with Integrated Air-Box. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Floating discs. 4 piston caliper. front brakes and Single disc. ABS. Floating disc. 2-piston caliper. rear brakes. The Indian Springfield was launched in 2021, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Quick Release Windshield. Cruise Control. Selectable Ride Modes. Keyless Ignition. 12v Charging Port.
