2021 Norton Atlas Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2021 Norton Atlas .

Basic Specs

Norton Atlas
Year2021
MakeNorton
ModelNorton Atlas
CostUS$ 12600. MSRP depends on country, taxes, accessories, etc.

Engine

Displacement650.0 ccm (39.66 cubic inches)
Type270-degree firing order
DetailsTwin, four-stroke
Max RPM
Compression11.5:1
Bore/Stroke82.0 x 61.5 mm (3.2 x 2.4 inches)
Valves/Cylinder2
FuelingInjection. 4 fuel injectors, drive-by-wire.
IgnitionKeyless
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox
Final Drive
Clutch
Driveline

Performance

Horespower84.0 HP (61.3 kW) @ 11000 RPM
Torque64.0 Nm (6.5 kgf-m or 47.2 ft.lbs)
Top Speed120.0 km/h (74.6 mph)

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity
Emissions

Chassis

Frame TypeTwin tube seamless steel perimeter chassis with aluminium swingarm mount.
Rake
Trail
Front Suspension50mm diameter Roadholder USD forks. Preload, compression and rebound adjustable.
Front Travel150 mm (5.9 inches)
Rear SuspensionRoadholder monoshock with rising rate linkage and piggyback reservoir. Adjustable preload.
Rear Travel150 mm (5.9 inches)
Seat
Seat Height
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance
Wheelbase1446 mm (56.9 inches)
Dry Weight178.0 kg (392.4 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre110/80-R18
Rear Tire/Tyre180/55-R17
Front BrakesDouble disc. Full floating Brembo discs. Radially mounted twin Brembo monoblock callipers with ABS. Brembo master cylinder.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. Brembo twin piston rear calliper with ABS. Brembo master cylinder.
Rear Brake Diameter245 mm (9.6 inches)
WheelsAvon Trekrider tires

Comments

It appears you're interested in specifications for the Norton Atlas . This Allround model is powered by a 270-degree firing order Twin, four-stroke engine with 650.0 ccm (39.66 cubic inches) of actual displacement before 11.5:1 compression. Fueling is metered via Injection. 4 fuel injectors, drive-by-wire. allowing this machine to produce its 84.0 HP (61.3 kW) @ 11000 RPM horsepower and 64.0 Nm (6.5 kgf-m or 47.2 ft.lbs) torque. According to our records engine heat of the Norton Atlas is moderated by Liquid. You'll need to get familiar with the transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 110/80-R18 and the rear is 180/55-R17 . The entire package is supported by the frame, Twin tube seamless steel perimeter chassis with aluminium swingarm mount. . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Full floating Brembo discs. Radially mounted twin Brembo monoblock callipers with ABS. Brembo master cylinder. front brakes and Single disc. Brembo twin piston rear calliper with ABS. Brembo master cylinder. rear brakes. The Norton Atlas was launched in 2021, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Norton is now owned by TVS motor.
