2021 QJmotor QJ500-11A Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2021 QJmotor QJ500-11A.

Basic Specs

QJmotor QJ500-11A
Year2021
MakeQJmotor
ModelQJmotor QJ500-11A
Cost

Engine

Displacement500.0 ccm (30.51 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression8.5:1
Bore/Stroke86.0 x 90.0 mm (3.4 x 3.5 inches)
Valves/Cylinder
FuelingInjection
IgnitionTCI
Exhaust
LubricationForced and Splash
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
ClutchManual, Multiplate Wet
Driveline

Performance

Horespower25.5 HP (18.6 kW) @ 5500 RPM
Torque40.0 Nm (4.1 kgf-m or 29.5 ft.lbs) @ 4000 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity15.50 litres (4.10 US gallons)
Emissions

Chassis

Frame TypeCradle, steel
Rake
Trail
Front SuspensionTelescopic
Front Travel120 mm (4.7 inches)
Rear SuspensionUnit Swing
Rear Travel60 mm (2.4 inches)
Seat
Seat Height700 mm (27.6 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1125 mm (44.3 inches)
Total Length2250 mm (88.6 inches)
Total Width850 mm (33.5 inches)
Ground Clearance120 mm (4.7 inches)
Wheelbase1580 mm (62.2 inches)
Dry Weight
Wet Weight198.0 kg (436.5 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR18
Rear Tire/Tyre160/60-ZR17
Front BrakesSingle disc. Hydraulic.
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. Hydraulic.
Rear Brake Diameter240 mm (9.4 inches)
Wheels

Comments

It appears you're interested in specifications for the QJmotor QJ500-11A. This Allround model is powered by a Single cylinder, four-stroke engine with 500.0 ccm (30.51 cubic inches) of actual displacement before 8.5:1 compression. Fueling is metered via Injection allowing this machine to produce its 25.5 HP (18.6 kW) @ 5500 RPM horsepower and 40.0 Nm (4.1 kgf-m or 29.5 ft.lbs) @ 4000 RPM torque. According to our records engine heat of the QJmotor QJ500-11A is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/70-ZR18 and the rear is 160/60-ZR17 . The entire package is supported by the frame, Cradle, steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Hydraulic. front brakes and Single disc. Hydraulic. rear brakes. The QJmotor QJ500-11A was launched in 2021, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

The Chinese firm QJMotor is owned by Qianjiang that has bought Benelli, Keeway and KSR.
