2021 Suzuki QuadSport Z50 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2021 Suzuki QuadSport Z50.

Basic Specs

Suzuki QuadSport Z50
Year2021
MakeSuzuki
ModelSuzuki QuadSport Z50
TypeATV
CostUS$ 2149. MSRP depends on country, taxes, accessories, etc.

Engine

Displacement49.0 ccm (2.99 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression8.4:1
Bore/Stroke36.0 x 48.6 mm (1.4 x 1.9 inches)
Valves/Cylinder
FuelingCarburettor. Mikuni VM13
IgnitionCDI
Exhaust
LubricationWet sump
CoolingAir

Drivetrain

GearboxAutomatic
Final Drive
Clutch
DrivelineCVT automatic. 2WD.

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity2.70 litres (0.71 US gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionIndependent single A-arm, oil-damped, coil-sprung
Front Travel
Rear SuspensionSwingarm, oil-damped, coil-sprung
Rear Travel
Seat
Seat Height535 mm (21.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height765 mm (30.1 inches)
Total Length1270 mm (50.0 inches)
Total Width765 mm (30.1 inches)
Ground Clearance120 mm (4.7 inches)
Wheelbase830 mm (32.7 inches)
Dry Weight
Wet Weight79.0 kg (174.2 pounds)

Wheels & Brakes

Front Tire/Tyre16/8-7
Rear Tire/Tyre16/8-7
Front BrakesExpanding brake (drum brake)
Front Brake Diameter
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Suzuki QuadSport Z50. This ATV model is powered by a Single cylinder, four-stroke engine with 49.0 ccm (2.99 cubic inches) of actual displacement before 8.4:1 compression. Fueling is metered via Carburettor. Mikuni VM13 allowing this machine to produce its horsepower and torque. According to our records engine heat of the Suzuki QuadSport Z50 is moderated by Air. You'll need to get familiar with the Automatic transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 16/8-7 and the rear is 16/8-7 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Expanding brake (drum brake) front brakes and Expanding brake (drum brake) rear brakes. The Suzuki QuadSport Z50 was launched in 2021, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
