2022 Honda CB650R Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2022 Honda CB650R.

Basic Specs

Honda CB650R
Year2022
MakeHonda
ModelHonda CB650R
TypeNaked bike
Cost
Service Manual
Classic Service Manual
Electric Service Manual

Engine

Displacement649.0 ccm (39.60 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression11.6:1
Bore/Stroke67.0 x 46.0 mm (2.6 x 1.8 inches)
Valves/Cylinder4
FuelingInjection. PGM-FI
IgnitionComputer-controlled digital transistorised with electronic advance
Exhaust
Lubrication
CoolingLiquid
Spark Plugs

Drivetrain

Gearbox6-speed
Final Drive
ClutchWet, multiplate with coil springs
Driveline525 O-ring sealed chain
Clutch Plates

Performance

Horespower93.9 HP (68.5 kW) @ 12000 RPM
Torque63.0 Nm (6.4 kgf-m or 46.5 ft.lbs) @ 9500 RPM
Top Speed
K&N Air Filter Slip-on Exhaust

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity15.40 litres (4.07 US gallons)
Emissions
Fuel Bottles & Cans

Chassis

Frame TypeSteel diamond
Rake25.5 deg
Trail101 mm (4.0 inches)
Front Suspension41mm Showa Separate Function front Fork Big Piston (SFF-BP) USD forks
Front Travel
Rear SuspensionMonoshock damper with 7 stage adjustable preload,
Rear Travel
Seat
Seat Height810 mm (31.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1075 mm (42.3 inches)
Total Length2130 mm (83.9 inches)
Total Width780 mm (30.7 inches)
Ground Clearance130 mm (5.1 inches)
Wheelbase1450 mm (57.1 inches)
Dry Weight
Wet Weight202.5 kg (446.4 pounds)
Seats & Covers Lowering Kits Titanium

Wheels & Brakes

Front Tire/Tyre120/70-17
Rear Tire/Tyre180/55-17
Front BrakesDouble disc. ABS. Radial-mount four-piston calipers.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. ABS Single-piston caliper.
Rear Brake Diameter240 mm (9.4 inches)
WheelsHollow-section 6-spoke cast aluminium
Front Brakes Pads Rear Brake Pads Front Tire Rear Tire

Comments

It appears you're interested in specifications for the Honda CB650R. This Naked bike model is powered by a In-line four, four-stroke engine with 649.0 ccm (39.60 cubic inches) of actual displacement before 11.6:1 compression. Fueling is metered via Injection. PGM-FI allowing this machine to produce its 93.9 HP (68.5 kW) @ 12000 RPM horsepower and 63.0 Nm (6.4 kgf-m or 46.5 ft.lbs) @ 9500 RPM torque. According to our records engine heat of the Honda CB650R is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/70-17 and the rear is 180/55-17 . The entire package is supported by the frame, Steel diamond. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Radial-mount four-piston calipers. front brakes and Single disc. ABS Single-piston caliper. rear brakes. The Honda CB650R was launched in 2022, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model id: CB650RA.
