2022 Honda CRF400RX Enduro Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2022 Honda CRF400RX Enduro.

Basic Specs

Honda CRF400RX Enduro
Year2022
MakeHonda
ModelHonda CRF400RX Enduro
Cost Euro 11390

Engine

Displacement413.0 ccm (25.20 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression13.0:1
Bore/Stroke92.0 x 62.1 mm (3.6 x 2.4 inches)
Valves/Cylinder4
FuelingInjection. Programmed Fuel Injection (PGM-FI), 46mm downdraft throttle body
IgnitionDC-CDI
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final Drive
ClutchMulti plate wet
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity7.95 litres (2.10 US gallons)
Emissions

Chassis

Frame TypeAluminium frame and swingarm
Rake27.7 deg
Trail114 mm (4.5 inches)
Front Suspension49mm leading-axle inverted telescopic Showa coil-spring fork with rebound and compression damping adjustability
Front Travel310 mm (12.2 inches)
Rear SuspensionPro-Link Showa single shock with adjustable spring preload, rebound and compression damping adjustability
Rear Travel312 mm (12.3 inches)
Seat
Seat Height965 mm (38.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1282 mm (50.5 inches)
Total Length2182 mm (85.9 inches)
Total Width839 mm (33.0 inches)
Ground Clearance336 mm (13.2 inches)
Wheelbase1481 mm (58.3 inches)
Dry Weight
Wet Weight111.8 kg (246.5 pounds)

Wheels & Brakes

Front Tire/Tyre90/90-21
Rear Tire/Tyre120/90-18
Front BrakesSingle disc. Hydraulic. Two-piston calipers.
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc. Hydraulic
Rear Brake Diameter240 mm (9.4 inches)
WheelsDunlop Geomax AT81 tires.

Comments

It appears you're interested in specifications for the Honda CRF400RX Enduro. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 413.0 ccm (25.20 cubic inches) of actual displacement before 13.0:1 compression. Fueling is metered via Injection. Programmed Fuel Injection (PGM-FI), 46mm downdraft throttle body allowing this machine to produce its horsepower and torque. According to our records engine heat of the Honda CRF400RX Enduro is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 90/90-21 and the rear is 120/90-18 . The entire package is supported by the frame, Aluminium frame and swingarm. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Hydraulic. Two-piston calipers. front brakes and Single disc. Hydraulic rear brakes. The Honda CRF400RX Enduro was launched in 2022, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Part of RedMoto Honda range in Europe. All bikes are built in-house using the race team for all R and D.
