2007 Harley-Davidson FXDC Dyna Super Glide Custom Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2007 Harley-Davidson FXDC Dyna Super Glide Custom.

Basic Specs

Year2007
MakeHarley-Davidson
ModelHarley-Davidson FXDC Dyna Super Glide Custom
CostUS$ 14645. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1573.25 ccm (96.00 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression9.2:1
Bore/Stroke95.3 x 111.3 mm (3.8 x 4.4 inches)
Valves/Cylinder
FuelingInjection. Electronic Sequential Port Fuel Injection (ESPFI)
Ignition
ExhaustChrome, staggered shorty duals
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveBelt
ClutchMulti-plate with diaphragm spring in oil bath
Driveline

Performance

Horespower
Torque124.75 Nm (12.7 kgf-m or 92.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption4.43 litres/100 km (22.6 km/l or 53.10 mpg)
Fuel Capacity19.30 litres (5.10 gallons)
Emissions102.8 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake29.0°
Trail
Front Suspension
Front Travel
Rear Suspension
Rear Travel
Seat
Seat Height706 mm (27.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,360 mm (92.9 inches)
Total Width
Ground Clearance152 mm (6.0 inches)
Wheelbase1,631 mm (64.2 inches)
Dry Weight292.6 kg (645.0 pounds)
Wet Weight306.6 kg (676.0 pounds)

Wheels & Brakes

Front Tire/Tyre100/90-H19
Rear Tire/Tyre160/70-B17
Front BrakesSingle disc. 4-piston
Front Brake Diameter
Rear BrakesSingle disc. 4-piston
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Harley-Davidson FXDC Dyna Super Glide Custom. This Custom / cruiser model is powered by a V2, four-stroke engine with 1573.25 ccm (96.00 cubic inches) of actual displacement before 9.2:1 compression. Fueling is metered via Injection. Electronic Sequential Port Fuel Injection (ESPFI) allowing this machine to produce its horsepower and 124.75 Nm (12.7 kgf-m or 92.0 ft.lbs) torque. According to our records engine heat of the Harley-Davidson FXDC Dyna Super Glide Custom is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 100/90-H19 and the rear is 160/70-B17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. 4-piston front brakes and Single disc. 4-piston rear brakes. The Harley-Davidson FXDC Dyna Super Glide Custom was launched in 2007, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
