2014 Husqvarna FE501 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2014 Husqvarna FE501.

Basic Specs

Year2014
MakeHusqvarna
ModelHusqvarna FE501
Cost

Engine

Displacement510.40 ccm (31.14 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke95.0 x 72.0 mm (3.7 x 2.8 inches)
Valves/Cylinder
FuelingInjection
IgnitionContactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Exhaust
LubricationForced oil lubrication with 2 Eaton pumps
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchWet multi-disc clutch DDS / Brembo hydraulics
Driveline520 X-Ring chain

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity9.50 litres (2.51 gallons)
Emissions

Chassis

Frame TypeCentral tube frame made of chrome molybdenum steel tubing
Rake26.5°
Trail
Front SuspensionWP Suspension Up Side Down 4CS
Front Travel300 mm (11.8 inches)
Rear SuspensionWP Monoshock with linkage
Rear Travel330 mm (13.0 inches)
Seat
Seat Height970 mm (38.2 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,260 mm (89.0 inches)
Total Width
Ground Clearance345 mm (13.6 inches)
Wheelbase1,482 mm (58.3 inches)
Dry Weight113.5 kg (250.2 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre90/90-21
Rear Tire/Tyre140/90-18
Front BrakesSingle disc. Four-pot brake caliper
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc. One-pot brake caliper, floating brake discs
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Husqvarna FE501. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 510.40 ccm (31.14 cubic inches) of actual displacement before compression. Fueling is metered via Injection allowing this machine to produce its horsepower and torque. According to our records engine heat of the Husqvarna FE501 is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 90/90-21 and the rear is 140/90-18 . The entire package is supported by the frame, Central tube frame made of chrome molybdenum steel tubing. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Four-pot brake caliper front brakes and Single disc. One-pot brake caliper, floating brake discs rear brakes. The Husqvarna FE501 was launched in 2014, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
