2016 ATK GV250 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 ATK GV250.

Basic Specs

Year2016
MakeATK
ModelATK GV250
TypeCustom / cruiser
Cost
Service Manual
Classic Service Manual
Electric Service Manual

Engine

Displacement249.00 ccm (15.19 cubic inches)
Type75° V-twin
DetailsV2, four-stroke
Max RPM
Compression10.3:1
Bore/Stroke57.0 x 48.8 mm (2.2 x 1.9 inches)
Valves/Cylinder4
FuelingInjection. EFI, optional Mikuni carburator
Ignition
Exhaust
LubricationWet sump
CoolingOil & air
Spark Plugs

Drivetrain

Gearbox5-speed
Final DriveChain
ClutchMulti-disc in oil bath.
Driveline520 chain
Chain Clutch Plates

Performance

Horespower25.00 HP (18.2 kW)
Torque22.04 Nm (2.2 kgf-m or 16.3 ft.lbs)
Top Speed
K&N Air Filter Slip-on Exhaust

Fuel Economy & Polution

Fuel Consumption3.36 litres/100 km (29.8 km/l or 70.01 mpg)
Fuel Capacity14.00 litres (3.70 gallons)
Emissions78.0 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel Bottles & Cans

Chassis

Frame TypeSteel
Rake
Trail
Front SuspensionConventional telescopic fork
Front Travel
Rear Suspension Swing arm with progressive linkage hydraulic dual shock absorber
Rear Travel
SeatDual seat
Seat Height762 mm (30.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,096 mm (82.5 inches)
Total Width
Ground Clearance196 mm (7.7 inches)
Wheelbase1,435 mm (56.5 inches)
Dry Weight149.7 kg (330.0 pounds)
Wet Weight
Seats & Covers Lowering Kits Titanium

Wheels & Brakes

Front Tire/Tyre110/90-ZR16
Rear Tire/Tyre150/80-ZR15
Front BrakesDouble disc. 2 pistons calipers
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter
WheelsCast aluminium, 5-spoke
Front Brakes Pads Rear Brake Pads Front Tire Rear Tire

Comments

It appears you're interested in specifications for the ATK GV250. This Custom / cruiser model is powered by a 75° V-twin V2, four-stroke engine with 249.00 ccm (15.19 cubic inches) of actual displacement before 10.3:1 compression. Fueling is metered via Injection. EFI, optional Mikuni carburator allowing this machine to produce its 25.00 HP (18.2 kW) horsepower and 22.04 Nm (2.2 kgf-m or 16.3 ft.lbs) torque. According to our records engine heat of the ATK GV250 is moderated by Oil & air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 110/90-ZR16 and the rear is 150/80-ZR15 . The entire package is supported by the frame, Steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. 2 pistons calipers front brakes and Expanding brake (drum brake) rear brakes. The ATK GV250 was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Sold in the US.
