2019 Ducati Monster 1200 S Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2019 Ducati Monster 1200 S.

Basic Specs

Year2019
MakeDucati
ModelDucati Monster 1200 S
Cost

Engine

Displacement1198.00 ccm (73.10 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression13.0:1
Bore/Stroke106.0 x 67.9 mm (4.2 x 2.7 inches)
Valves/Cylinder4
FuelingInjection. 53mm throttle bodies with full Ride by Wire
Ignition
ExhaustLightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchLight action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Driveline

Performance

Horespower147.00 HP (107.3 kW)
Torque124.00 Nm (12.6 kgf-m or 91.5 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption5.20 litres/100 km (19.2 km/l or 45.23 mpg)
Fuel Capacity16.50 litres (4.36 gallons)
Emissions120.6 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeTubular steel Trellis frame attached to the cylinders head
Rake23.3°
Trail93 mm (3.7 inches)
Front Suspension43mm Ölins fully adjustable usd fork
Front Travel130 mm (5.1 inches)
Rear SuspensionProgressive linkage with Ohlins monoshock, preload and rebound adjustable, Aluminium single-sided swingarm
Rear Travel149 mm (5.9 inches)
SeatDual seat
Seat Height785 mm (30.9 inches) If adjustable, lowest setting.
Alt. Seat Height810 mm (31.9 inches) If adjustable, highest setting.
Total Height1,040 mm (40.9 inches)
Total Length2,200 mm (86.6 inches)
Total Width830 mm (32.7 inches)
Ground Clearance
Wheelbase1,485 mm (58.5 inches)
Dry Weight185.0 kg (407.9 pounds)
Wet Weight211.0 kg (465.2 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre190/55-ZR17
Front BrakesDouble disc. ABS. Floating discs. Four-piston calipers. Radially mounted.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. ABS. Floating disc. Two-piston calipers.
Rear Brake Diameter245 mm (9.6 inches)
WheelsY-shaped 3-spoke in light alloy

Comments

It appears you're interested in specifications for the Ducati Monster 1200 S. This Naked bike model is powered by a V2, four-stroke engine with 1198.00 ccm (73.10 cubic inches) of actual displacement before 13.0:1 compression. Fueling is metered via Injection. 53mm throttle bodies with full Ride by Wire allowing this machine to produce its 147.00 HP (107.3 kW) horsepower and 124.00 Nm (12.6 kgf-m or 91.5 ft.lbs) torque. According to our records engine heat of the Ducati Monster 1200 S is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 190/55-ZR17 . The entire package is supported by the frame, Tubular steel Trellis frame attached to the cylinders head. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Floating discs. Four-piston calipers. Radially mounted. front brakes and Single disc. ABS. Floating disc. Two-piston calipers. rear brakes. The Ducati Monster 1200 S was launched in 2019, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
